Details
Müüdavad tooted
| range of product | OsiSense XCC | |
|---|---|---|
| encoder type | Multiturn absolute encoder | |
| device short name | XCC | |
| product specific application | - | |
| diameter | 58 mm | |
| shaft diameter | 14 mm | |
| shaft type | Through shaft | |
| resolution | 4096 turns/8192 points | |
| electrical connection | 1 male connector M23 radial 12 pins | |
| output stage | Type SB | |
| type of output stage | SSI 25-bit binary | |
| [Us] rated supply voltage | 11...30 V DC | |
| enclosure material | Steel |
| shaft tolerance | H7 | |
|---|---|---|
| residual ripple | 500 mV | |
| maximum revolution speed | 6000 rpm | |
| shaft moment of inertia | 22 g.cm² | |
| torque value | 0,006 N.m | |
| maximum load | 2 daN axial5 daN radial | |
| output frequency | 100…500 kHz | |
| current consumption | 0...100 mA no-load | |
| protection type | Reverse polarity protectionShort-circuit protection | |
| physical interface | RS422 | |
| output level | High level: 2 V minimum 20 mA | |
| surge withstand | 1 kV, level 2 IEC 61000-4-5 | |
| base material | Aluminium | |
| shaft material | Stainless steel | |
| type of ball bearings | 6803ZZ | |
| net weight | 0,655 kg |
| marking | CE | |
|---|---|---|
| ambient air temperature for operation | -20…85 °C | |
| ambient air temperature for storage | -20…85 °C | |
| IP degree of protection | IP65 IEC 60529 | |
| vibration resistance | 10 gn 10…2000 Hz)IEC 60068-2-6 | |
| shock resistance | 30 gn 11 ms IEC 60068-2-27 | |
| resistance to electrostatic discharge | 4 kV contact discharge) level 3 IEC 61000-4-28 kV air discharge) level 3 IEC 61000-4-2 | |
| resistance to electromagnetic fields | 10 V/m level 3 IEC 61000-4-3 | |
| resistance to fast transients | 1 kV signal ports level 3 IEC 61000-4-42 kV power ports level 3 IEC 61000-4-4 |
| Ilma SVHC REACh-ta | Jah | |
|---|---|---|
| ELi RoHS direktiiv | Ennetav vastavus (toode ei jää EL-i RoHS seadustega määratud piiridesse) ELi RoHS deklaratsioon | |
| Mürgiste raskemetallideta | Jah | |
| Elavhõbedavaba | Jah | |
| RoHS eranditeave |
| Garantii | 18 months |
|---|
