Details
Characteristics
| range of product | Acti 9 | |
|---|---|---|
| product name | Acti 9 TH | |
| product or component type | Thermostat | |
| device short name | TH7 | |
| number of zones | 1 | |
| provided equipment | Supplied without probe |
| operating mode | Normal: -40…80 °C | |
|---|---|---|
| measurement accuracy | +/- 0.2 °C | |
| maximum power consumption in VA | 4 VA | |
| maximum switching current | 16 A - 250 V pf = 13 A - 250 V pf = 0.6 | |
| [Ue] rated operational voltage | 230 V AC +/- 10 % | |
| protection type | Over temperature protectionOver voltage protection against surges | |
| status LED | Indicator light (red)make position of the output contacts: | |
| mounting support | DIN rail | |
| 9 mm pitches | 5 | |
| connections - terminals | Screwless terminals 2, cable cross section: 2.5 mm² | |
| colour tint | White (RAL 9003) | |
| height | 85 mm | |
| width | 45 mm | |
| depth | 65 mm |
| standards | EN 60730-2-9 | |
|---|---|---|
| IP degree of protection | IP20 |
| Sustainable offer status | Green Premium product | |
|---|---|---|
| EU RoHS Directive | Compliant EU RoHS Declaration | |
| Toxic heavy metal free | Yes | |
| Mercury free | Yes | |
| RoHS exemption information | ||
| China RoHS Regulation | China RoHS declaration Pro-active China RoHS declaration (out of China RoHS legal scope) | |
| Environmental Disclosure | ||
| WEEE | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins |
| Warranty | 18 months |
|---|
