analog input module Modicon Quantum - 8 I Ni / Pt 100, 200, 500, 1000

Ülevaaded: 0

Tootekood: 140ARI03010C

Quick Overview

Saadavus: Ei saa enam tellida

1 576,52 € (ilma KM-ta)

Details

Main
range of product
Modicon Quantum automation platform
product or component type
Analogue input module
Complementary
analogue input number
8
input type
Differential
addressing requirement
9 input words
analogue input type
Temperature probe: - 100...450 °C for Pt 100, Pt 200, Pt 500, Pt 1000
Temperature probe: - 200...850 °C for Pt 100, Pt 200, Pt 500, Pt 1000
Temperature probe: - 60...180 °C for Ni 100, Ni 200, Ni 500, Ni 1000
Temperature probe: 0.5 mA for Ni 100, Ni 200, Ni 500, Ni 1000
Temperature probe: 2.5 mA for Pt 100, Pt 200, Ni 100, Ni 200
analogue input resolution
13 bits
input impedance
>= 10 MOhm
absolute accuracy error
0.1 °C
linearity error
+/- 0.01 % full scale
+/- 0.5 °C
accuracy drift according to temperature
+/- 0.5 °C at 25 °C
+/- 0.9 °C at 0…60 °C
isolation between channels and bus
1780 V AC 47...63 Hz for 60 s
2500 V DC for 60 s
isolation between channels
300 Vrms AC
update time
1200 ms 3 wires
640 ms 2 wires/4 wires
fault type
Broken wire
Overtacking scale
marking
CE
local signalling
1 LED (green)bus communication is present (Active):
1 LED (red)external fault:
8 LEDs (green)channel is turned on:
8 LEDs (red)channel fault:
bus current requirement
200 mA
power dissipation in W
1 W
module format
Standard
net weight
0.3 kg
Environment
protective treatment
Conformal coating Humiseal 1A33
standards
UL 508
CSA C22.2 No 142
product certifications
FM Class 1 Division 2
CUL
resistance to electrostatic discharge
4 kV contact conforming to IEC 801-2
8 kV on air conforming to IEC 801-2
resistance to electromagnetic fields
10 V/m 80…1000 MHz conforming to IEC 801-3
ambient air temperature for operation
0…60 °C
ambient air temperature for storage
-40…85 °C
relative humidity
95 % without condensation
operating altitude
<= 5000 m
Offer Sustainability
Sustainable offer status
Green Premium product
REACh Regulation
EU RoHS Directive
Pro-active compliance (Product out of EU RoHS legal scope)
EU RoHS Declaration
Mercury free
Yes
RoHS exemption information
China RoHS Regulation
Environmental Disclosure
Circularity Profile
WEEE
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Contractual warranty
Warranty
18 months
