battery- 24 V DC - 32 A - 3.2 AH - for battery control module

Product was successfully added to your shopping cart.

battery- 24 V DC - 32 A - 3.2 AH - for battery control module

Tootekood: ABL8BPK24A03

Quick Overview

Saadavus: Tellimisel

173,90 € (ilma KM-ta)

Qty:

Details

Main
range of product	Phaseo
product or component type	Battery module
input voltage	24 V DC
output voltage	24 V DC
maximum output current	32 A
battery capacity	3,2 Ah
holding time	< 20 h 0.16 A, 20 °C > 5 min 8.4 A, 20 °C

Complementary
input voltage limits	21...29 V
charging time	72 h
load current	0,3 A
output protection type	Against overload and short-circuits 1 x 20 A automotive type fuse
connections - terminals	Input connection screw type terminals 2 x 0.5...2 x 10 mm² AWG 20...AWG 8 Output connection screw type terminals 2 x 0.5...2 x 10 mm² AWG 20...AWG 8
self-discharge rate	9 %, 3 months 3 %, 1 month 15 %, 6 months
fixing mode	By 2 screws 5 mm horizontal panel horizontal By 4 screws 5 mm vertical panel vertical By clips (with mounting kit) 35 mm symmetrical DIN rail horizontal By clips (with mounting kit) 35 mm symmetrical DIN rail vertical
output coupling	Parallel
operating altitude	2000 m
service life in hours	11000 h 40 °C 15000 h 35 °C 22000 h 30 °C 31000 h 25 °C 44000 h 20 °C 5000 h 50 °C 7300 h 45 °C
marking	CE
net weight	3,5 kg

Environment
product certifications	GOST UL
ambient air temperature for operation	0…40 °C
ambient air temperature for storage	-20…50 °C
IP degree of protection	IP10 EN/IEC 60529
overvoltage category	Class 3 VDE 0106-1
vibration resistance	2 gn 11,9…150 Hz)EN/IEC 61131-2 3.5 mm 3…11,9 Hz)EN/IEC 61131-2

Offer Sustainability
ELi RoHS direktiiv	Ei rakendu, ei jää EL-i RoHS seadustega määratud piiridesse
Hiina EoHS regulatsioon	Hiina RoHS deklaratsioon Toode ei kuulu Hiina RoHS sfääri. Ainedeklaratsioon teavitamiseks.
Keskkonnaalane avaldus	Toote keskkonnaprofiil
Ringlusprofiil	Kasutuselt kõrvaldamise teave

Contractual warranty
Garantii	18 months
