battery - 24 V DC - 75 A - 7 AH - for battery control module

Ülevaaded: 0

Tootekood: ABL8BPK24A12

Quick Overview

Saadavus: Tellimisel

257,21 € (ilma KM-ta)

Details

Main
range of product
Phaseo
product or component type
Battery module
input voltage
24 V DC
output voltage
24 V DC
maximum output current
75 A
battery capacity
12 Ah
holding time
< 20 h 0.6 A, 20 °C
> 5 min 31.3 A, 20 °C
Complementary
input voltage limits
21...29 V
charging time
72 h
load current
1,2 A
output protection type
Against overload and short-circuits 2 x 30 A automotive type fuses
connections - terminals
Input connection screw type terminals 4 x 0.5...4 x 10 mm² AWG 20...AWG 8
Output connection screw type terminals 4 x 0.5...4 x 10 mm² AWG 20...AWG 8
self-discharge rate
15 %, 6 months
9 %, 3 months
3 %, 1 month
fixing mode
By 2 screws 5 mm horizontal panel horizontal
By 4 screws 5 mm vertical panel vertical
output coupling
Parallel
operating altitude
2000 m
service life in hours
11000 h 40 °C
15000 h 35 °C
22000 h 30 °C
31000 h 25 °C
44000 h 20 °C
5000 h 50 °C
7300 h 45 °C
marking
CE
net weight
12 kg
Environment
product certifications
UL
GOST
ambient air temperature for operation
0…40 °C
ambient air temperature for storage
-20…50 °C
IP degree of protection
IP10 EN/IEC 60529
overvoltage category
Class 3 VDE 0106-1
vibration resistance
2 gn 11,9…150 Hz)EN/IEC 61131-2
3.5 mm 3…11,9 Hz)EN/IEC 61131-2
Offer Sustainability
ELi RoHS direktiiv
Ei rakendu, ei jää EL-i RoHS seadustega määratud piiridesse
Hiina EoHS regulatsioon
Hiina RoHS deklaratsioon
Toode ei kuulu Hiina RoHS sfääri. Ainedeklaratsioon teavitamiseks.
Keskkonnaalane avaldus
Ringlusprofiil
Contractual warranty
Garantii
18 months
