  • capacitive sensor - XT7 - 40 x 40 x 117 - plastic - Sn 15 mm - 24..240 V AC

Product was successfully added to your shopping cart.

capacitive sensor - XT7 - 40 x 40 x 117 - plastic - Sn 15 mm - 24..240 V AC

Ülevaaded: 0

Tootekood: XT7C40FP262

Quick Overview

Saadavus: Ei saa enam tellida

265,62 € (ilma KM-ta)

Details

Main
range of product
OsiSense XT
sensor type
Capacitive proximity sensor
product specific application
Detection of insulated materials
sensor name
XT7
sensor design
Form 40 x 40 x 117
size
117 mm
body type
Plug-in body
detector flush mounting acceptance
Flush mountable
material
Plastic
enclosure material
Plastic
type of output signal
Discrete
wiring technique
2-wire
[Sn] nominal sensing distance
15 mm
discrete output function
1 NO or 1 NC programmable
output circuit type
AC
electrical connection
Screw clamp terminal, 3 x 1.5 mm²
[Us] rated supply voltage
24...240 V AC 50...60 Hz
maximum delay response
20 ms
IP degree of protection
IP67 IEC 60529
Complementary
detection face
5 positions turret head
differential travel
< 0.2 x Sr
repeat accuracy
< 0.1 x Sr
cable entry
1 entry tapped for Pg 13.5 cable gland
status LED
Supply state indication 1 LED green)
Output state indication 1 LED yellow)
supply voltage limits
20…264 V AC
maximum residual current
1,5 mA open state
switching frequency
<= 25 Hz
maximum voltage drop
<5,5 V closed)
maximum delay first up
150 ms
maximum delay recovery
30 ms
maximum switching current
350 mA
marking
CE
setting-up
Sensitivity by potentiometer
depth
40 mm
height
117 mm
width
40 mm
net weight
0,22 kg
Environment
product certifications
UL
CSA
ambient air temperature for operation
-25…70 °C
Offer Sustainability
REACh-määrus
ELi RoHS direktiiv
Ennetav vastavus (toode ei jää EL-i RoHS seadustega määratud piiridesse)
ELi RoHS deklaratsioon
Elavhõbedavaba
Jah
RoHS eranditeave
Contractual warranty
Garantii
18 months
