cartridge C40-340 for surge arrester iPRD

Ülevaaded: 0

Tootekood: A9L16685

Quick Overview

Saadavus: Ei saa enam tellida

15,49 € (ilma KM-ta)

Details

Main
product or component type
Cartridge
device short name
C40-340
surge arrester type
Electrical distribution network
Complementary
surge arrester class type
Type 2
surge arrester technology
MOV
earthing system
TT
TN
[Ue] rated operational voltage
230 V AC 50 Hz
nominal discharge current
15 kA
maximum discharge current
40 kA
[Uc] maximum continuous operating voltage
340 V
maximum [Up] voltage protection level
<1.4 kV type 2
local signalling
White/red flag
mounting mode
Plug-in
mounting support
Into SPD module
9 mm pitches
2
height
50 mm
width
18 mm
depth
60 mm
colour
White (RAL 9003)
material
PBT (polybutylene terephthalate)
response time
< 25 ns
Environment
standards
EN 61643-11
IEC 61643-1
product certifications
OVE
NF
KEMA-KEUR
IP degree of protection
IP20 front face:
relative humidity
5…90 %
operating altitude
0...2000 m
ambient air temperature for operation
-25…60 °C
ambient air temperature for storage
-40…85 °C
Offer Sustainability
Sustainable offer status
Green Premium product
EU RoHS Directive
Pro-active compliance (Product out of EU RoHS legal scope)
EU RoHS Declaration
Environmental Disclosure
Contractual warranty
Warranty
18 months
