circuit breaker basic frame, Compact NS 800bLB, 200 kA at 415 VAC 50/60 Hz, 800 A, fixed, manually operated, without trip unit, 4 poles

Ülevaaded: 0

Tootekood: 48956

Quick Overview

Saadavus: Tellimisel

2 327,25 € (ilma KM-ta)

Details

Main
range of product
NS630b...1600
product or component type
Basic frame
device short name
Compact NS800LB
device application
Distribution
circuit breaker name
Compact NS800LB
poles description
4P
neutral position
Left
network type
AC
breaking capacity code
LB
suitability for isolation
Yes IEC 60947-2
utilisation category
Category A
Complementary
network frequency
50/60 Hz
control type
Rotary handle
Toggle
mounting mode
Fixed
mounting support
Backplate
(In) rated current up to 65 °C
800 A 50 °C
[Ui] rated insulation voltage
800 V AC 50/60 Hz IEC 60947-2
[Uimp] rated impulse withstand voltage
8 kVIEC 60947-2
[Ue] rated operational voltage
690 V AC 50/60 Hz IEC 60947-2
circuit breaker CT rating
800 A
breaking capacity
200 kA Icu 220/240 V AC 50/60 Hz IEC 60947-2
200 kA Icu 380/415 V AC 50/60 Hz IEC 60947-2
200 kA Icu 440 V AC 50/60 Hz IEC 60947-2
75 kA Icu 660/690 V AC 50/60 Hz IEC 60947-2
100 kA Icu 500/525 V AC 50/60 Hz IEC 60947-2
[Ics] rated service breaking capacity
200 kA 220/240 V AC 50/60 Hz EN 60947-2 manual operation)
200 kA 440 V AC 50/60 Hz IEC 60947-2 manual operation)
200 kA 380/415 V AC 50/60 Hz EN 60947-2 manual operation)
75 kA 660/690 V AC 50/60 Hz IEC 60947-2 manual operation)
100 kA 500/525 V AC 50/60 Hz EN 60947-2 manual operation)
protection type
Without protection
mechanical durability
10000 cycles IEC 60947-2
electrical durability
2000 cycles 690 V In IEC 60947-2
3000 cycles 440 V In IEC 60947-2
3000 cycles 690 V In/2 IEC 60947-2
4000 cycles 440 V In/2 IEC 60947-2
connection pitch
70 mm
height
327 mm
width
280 mm
depth
147 mm
Environment
standards
IEC 60947-2
product certifications
ASTA
LCIE
ASEFA
power losses
20 W
IP degree of protection
IP40IEC 60529
IK degree of protection
IK07 EN 50102
pollution degree
3 IEC 60947
ambient air temperature for operation
-25…70 °C
ambient air temperature for storage
-50…85 °C
Offer Sustainability
Ilma SVHC REACh-ta
Jah
ELi RoHS direktiiv
Ennetav vastavus (toode ei jää EL-i RoHS seadustega määratud piiridesse)
ELi RoHS deklaratsioon
Mürgiste raskemetallideta
Jah
Elavhõbedavaba
Jah
RoHS eranditeave
Hiina EoHS regulatsioon
Contractual warranty
Garantii
18 months
