circuit breaker Compact NS100L - TMD - 25 A - 4 poles 3d

Ülevaaded: 0

Tootekood: 29724

Quick Overview

Saadavus: Tellimisel

695,75 € (ilma KM-ta)

Details

Main
range of product
Compact NS100...630
product or component type
Circuit breaker
device short name
Compact NS100L
circuit breaker name
Compact NS100L
device application
Distribution
poles description
4P
protected poles description
3t
neutral position
Left
network type
DC
AC
network frequency
50/60 Hz
[In] rated current
100 A at 40 °C
100 A at 65 °C
[Ui] rated insulation voltage
750 V AC 50/60 Hz conforming to IEC 60947-2
[Uimp] rated impulse withstand voltage
8 kV conforming to IEC 60947-2
[Ue] rated operational voltage
690 V AC 50/60 Hz conforming to IEC 60947-2
750 V DC conforming to IEC 60947-2
breaking capacity code
L
breaking capacity
130 kA at 480 V AC 50/60 Hz conforming to NEMA AB1 HIC
200 kA at 240 V AC 50/60 Hz conforming to NEMA AB1 HIC
50 kA at 600 V AC 50/60 Hz conforming to NEMA AB1 HIC
100 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2
100 kA Icu at 525 V AC 50/60 Hz conforming to IEC 60947-2
130 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2
150 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2
150 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2
75 kA Icu at 660/690 V AC 50/60 Hz conforming to IEC 60947-2
[Ics] rated service breaking capacity
50 kA at 500 V AC 50/60 Hz conforming to IEC 60947-2
130 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2
150 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2
150 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2
50 kA at 525 V AC 50/60 Hz conforming to IEC 60947-2
37.5 kA at 660/690 V AC 50/60 Hz conforming to IEC 60947-2
suitability for isolation
Yes conforming to IEC 60947-2
utilisation category
Category A
trip unit name
TM-D
trip unit technology
Thermal-magnetic
trip unit rating
25 A at 40 °C
protection type
Short-circuit protection (magnetic)
Overload protection (thermal)
pollution degree
3 conforming to IEC 60947
Complementary
control type
Toggle
mounting mode
Fixed
mounting support
Backplate
upside connection
Front
downside connection
Front
mechanical durability
50000 cycles
electrical durability
30000 cycles 440 V AC 50/60 Hz In conforming to IEC 60947-2
50000 cycles 440 V AC 50/60 Hz In/2 conforming to IEC 60947-2
connection pitch
35 mm
local signalling
Positive contact indication
neutral protection setting
No protection
long time pick-up adjustment type Ir
Adjustable
long time pick-up adjustment range
0.8...1 x In
instantaneous pick-up adjustment type Ii
Fixed
instantaneous pick-up adjustment range
300 A
height
161 mm
width
140 mm
depth
86 mm
Environment
standards
IEC 60947-2
product certifications
KEMA
LCIE
ASEFA
ASTA
IP degree of protection
IP40 conforming to IEC 60529
IK degree of protection
IK07 conforming to EN 50102
ambient air temperature for operation
-25…70 °C
ambient air temperature for storage
-50…85 °C
Contractual warranty
Warranty
18 months
