Details
Characteristics
| range of product | Modicon Quantum automation platform | |
|---|---|---|
| product or component type | DIO head-end adaptor |
| number of port | 1 Modbus Plus fiber optic single copper1 Modbus RS232 twisted pair | |
|---|---|---|
| transmission rate | 1 Mbit/s | |
| electrical connection | 1 connector RJ452 connectors TX/RX | |
| I/O words | 30 I/32 O | |
| checks | RAMRAM addressProcessorChecksum | |
| power dissipation in W | 4 W | |
| minimum pulse width distortion/jitter | 5 ns | |
| wavelength | 820 nm | |
| power loss budget | 11 dB 62.5/125 µm16.5 dB 100/140 µm6.5 dB 50/125 µm | |
| optical transmission | -16…-9 dBm 100/140 µm-19.8…-12.8 dBm 50/125 µm-3.5…110.5 dBm 62.5/125 µm | |
| rise/fall time | 20 ns | |
| dynamic range | 20 dB | |
| detected silence | -36 dBm | |
| sensitivity scale | > 30 dBm | |
| bus current requirement | 750 mA |
| resistance to electrostatic discharge | 4 kV contact conforming to IEC 801-28 kV on air conforming to IEC 801-2 | |
|---|---|---|
| resistance to electromagnetic fields | 10 V/m 80…2000 MHz conforming to IEC 801-3 | |
| ambient air temperature for operation | 0…60 °C | |
| ambient air temperature for storage | -40…85 °C | |
| relative humidity | 95 % without condensation | |
| operating altitude | <= 5000 m | |
| standards | UL 508 | |
| product certifications | CSA Class 1 Division 2RINAGLRMRSC-TickGOSTDNV |
| Sustainable offer status | Green Premium product | |
|---|---|---|
| REACh Regulation | ||
| EU RoHS Directive | Pro-active compliance (Product out of EU RoHS legal scope) EU RoHS Declaration | |
| Mercury free | Yes | |
| RoHS exemption information | ||
| China RoHS Regulation | ||
| Environmental Disclosure | ||
| Circularity Profile | ||
| WEEE | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins |
| Warranty | 18 months |
|---|
