discrete I/O module Modicon Momentum - 16 I/O relay

Product was successfully added to your shopping cart.

discrete I/O module Modicon Momentum - 16 I/O relay

Tootekood: 170ADM85010

Quick Overview

Saadavus: Tellimisel

727,99 € (ilma KM-ta)

Qty:

Details

Main
range of product	Modicon Momentum automation platform
product or component type	Discrete relay I/O base DC
group of channels	1 group of 16 outputs 1 group of 16 inputs
discrete input number	16 IEC 1131-2 Type 3
discrete input logic	Positive
discrete input voltage	24 V DC 12 V DC 48 V DC
discrete output number	16
discrete output type	Solid state switch
discrete output voltage	<= 60 V DC 12 V DC 24 V DC 48 V DC
discrete output logic	Positive
protective treatment	TC

Complementary
[Us] rated supply voltage	12 V DC 24 V DC 48 V DC
input voltage limits	10...60 V
voltage state 0 guaranteed	< 10 V 48 V < 2.5 V 12 V < 5 V 24 V
voltage state 1 guaranteed	> 11 V 24 V > 30 V 48 V > 7.5 V 12 V
current state 1 guaranteed	2.3 mA 12 V 2.7 mA 24 V 2.9 mA 48 V
discrete output current	0.5 A per point 7 A 60 °C per module 8 A 50 °C per group
maximum leakage current	1 mA 60 V output circuit)
peak output current	5 A
maximum voltage drop	<1 V 0,5 A at state 1 output circuit
fault type	Overload on output
response time	< 0.1 ms from state 0 to state 1 on output < 0.1 ms from state 1 to state 0 on output 2.2 ms from state 0 to state 1 on input 3.3 ms from state 1 to state 0 on input
isolation between group of I/O channels	707 V DC
isolation between channels and bus	707 V DC
power dissipation	6.0 + (0.144 x number of input points) + (0.25 x number of output points)
current consumption	250 mA 24 V DC 125 mA 48 V DC 500 mA 12 V DC
depth	47,5 mm
height	141,5 mm
width	125 mm

Environment
product certifications	FM Class 1 Division 2 UL CSA
resistance to electrostatic discharge	4 kV contact IEC 801-2 8 kV on air IEC 801-2
resistance to electromagnetic fields	10 V/m 80...1000 MHz IEC 801-3
ambient air temperature for operation	0…60 °C
ambient air temperature for storage	-40…85 °C
relative humidity	95 % without condensation
operating altitude	<= 5000 m

Offer Sustainability
Jätkusuutliku pakkumise olek	Green Premium toode
REACh-määrus	REACh-deklaratsioon
ELi RoHS direktiiv	Ennetav vastavus (toode ei jää EL-i RoHS seadustega määratud piiridesse) ELi RoHS deklaratsioon
Elavhõbedavaba	Jah
RoHS eranditeave	Jah
Hiina EoHS regulatsioon	Hiina RoHS deklaratsioon
Keskkonnaalane avaldus	Toote keskkonnaprofiil
Ringlusprofiil	Kasutuselt kõrvaldamise teave
WEEE	Tootest tuleb Euroopa Liidu turgudel vabaneda vastavuses erijäätmeseadustele ning see ei tohi sattuda olmeprügi sekka.

Contractual warranty
Garantii	18 months
