discrete I/O module Modicon Quantum - 4 I - 125 V DC - 4 O

Ülevaaded: 0

Tootekood: 140DDM69000C

Quick Overview

Saadavus: Ei saa enam tellida

1 362,26 € (ilma KM-ta)

Details

Main
range of product
Modicon Quantum automation platform
product or component type
Mixed discrete I/O module
discrete I/O number
8
Complementary
discrete input number
4 1 group of 8
discrete input logic
Sink
addressing requirement
1 output word
1 input word
network frequency limits
47…63 Hz
discrete input voltage
125 V DC
input voltage limits
156.2 V including ripple
voltage state 0 guaranteed
0...36 V
voltage state 1 guaranteed
88...156.2 V
current state 0 guaranteed
<= 1.2 mA
current state 1 guaranteed
>= 2 mA
response time
0.5 or 1.5 ms depending on the filter at at state 0 to state 1
0.5 or 1.5 ms depending on the filter at at state 1 to state 0
discrete output number
4 1 group of 4
discrete output type
Solid state, isolated
discrete output logic
Source or sink
discrete output voltage
24...125 V
output voltage limits
19.2...156.2 V DC typical
maximum load current
<= 16 A per module
<= 4 A per point
maximum voltage drop
<0.75 V 4 A
absolute maximum output
30 A during 500 ms per point
maximum load capacitance
0.1 µF 150 V DC
0.6 µF 24 V DC
maximum leakage current
1.2 mA 150 V DC
protection type
On input by resistor limited
On output by transient voltage suppression
Internal output protection by 5 A fuse per group
associated fuse rating
5 A
isolation between group of I/O channels
1780 Vrms for 1 minute
isolation between group and bus
2500 Vrms for 1 minute
isolation between channels
1780 Vrms for 1 minute
fault indication
Overcurrent on output
power dissipation
0.4 W + (1 x input point on) + (0.75 total output load current)
local signalling
1 LED (green)bus communication is present (Active):
1 LED (red)no voltage in output and input (F):
2 LEDs (red)fault detected on the output point:
4 LEDs (green)output is turned on:
4 LEDs (red)fault detected on the input point:
marking
CE
bus current requirement
350 mA
net weight
0.3 kg
Environment
resistance to electrostatic discharge
4 kV contact conforming to IEC 801-2
8 kV on air conforming to IEC 801-2
resistance to electromagnetic fields
10 V/m 80…1000 MHz conforming to IEC 801-3
ambient air temperature for operation
0…60 °C
ambient air temperature for storage
-40…85 °C
relative humidity
95 % without condensation
operating altitude
<= 5000 m
protective treatment
Conformal coating Humiseal 1A33
standards
FM Class 1 Division 2
UL 508
CSA C22.2 No 142
product certifications
CUL
Offer Sustainability
EU RoHS Directive
Pro-active compliance (Product out of EU RoHS legal scope)
EU RoHS Declaration
Environmental Disclosure
Circularity Profile
Contractual warranty
Warranty
18 months
