discrete input module Modicon Quantum - 16 inputs - 24 V AC

Ülevaaded: 0

Tootekood: 140DAI34000C

Quick Overview

Saadavus: Ei saa enam tellida

576,52 € (ilma KM-ta)

Details

Main
range of product
Modicon Quantum automation platform
product or component type
VAC discrete input modules
software name
Unity Pro
Concept
ProWORX 32
discrete input number
16
Complementary
group of channels
16
addressing requirement
1 input word
discrete input voltage
24 V AC
input current
12 mA at 57...63 Hz
10.7 mA at 47...53 Hz
voltage state 1 guaranteed
16...30 V AC at 57...63 Hz
18...30 V AC at 47...53 Hz
voltage state 0 guaranteed
0...6 V at 57...63 Hz
0...5 V at 47...53 Hz
input impedance
2600 Ohm capacitive at 57...63 Hz
3100 Ohm capacitive at 47...53 Hz
network frequency limits
47…63 Hz
maximum leakage current
1.9 mA
absolute maximum input
30 V continuous
32 V 10 s
50 V 1 cycle
response time
4.9...0.75 ms x line cycle Off-On
7.3...12.3 ms On-Off
isolation between channels
1780 Vrms for 1 minute
isolation between channels and bus
1780 Vrms for 1 minute
bus current requirement
180 mA
maximum power dissipation in W
5.5 W
local signalling
1 LED (green)bus communication is present (Active):
1 LED (red)external fault detected (F):
16 LEDs (green)input status:
marking
CE
module format
Standard
net weight
0.3 kg
Environment
protective treatment
Conformal coating Humiseal 1A33
standards
UL 508
CSA C22.2 No 142
product certifications
FM Class 1 Division 2
CUL
resistance to electrostatic discharge
4 kV contact conforming to IEC 801-2
8 kV on air conforming to IEC 801-2
resistance to electromagnetic fields
10 V/m 80…2000 MHz conforming to IEC 801-3
ambient air temperature for operation
0…60 °C
ambient air temperature for storage
-40…85 °C
relative humidity
95 % without condensation
operating altitude
<= 5000 m
Contractual warranty
Warranty
18 months
