discrete input module Modicon Quantum - 32 I - 48 V AC

Ülevaaded: 0

Tootekood: 140DAI45300

Quick Overview

Saadavus: Tellimisel

1 166,86 € (ilma KM-ta)

Details

Main
range of product
Modicon Quantum automation platform
product or component type
VAC discrete input modules
software name
ProWORX 32
Concept
Unity Pro
discrete input number
32
Complementary
group of channels
4
addressing requirement
2 input words
discrete input voltage
48 V AC
input current
11.7 mA at 57...63 Hz
9.8 mA at 47...53 Hz
voltage state 1 guaranteed
29...56 V AC at 57...63 Hz
34...56 V AC at 47...53 Hz
voltage state 0 guaranteed
0...10 V AC at 57...63 Hz
0...10 V AC at 47...53 Hz
input impedance
5600 Ohm capacitive at 57...63 Hz
6800 Ohm capacitive at 47...53 Hz
network frequency limits
47…63 Hz
maximum leakage current
1.7 mA
absolute maximum input
100 V 1 cycle
56 V continuous
63 V 10 s
response time
4.9...0.75 ms x line cycle Off-On
7.3...12.3 ms On-Off
isolation between group
1780 Vrms for 1 minute
isolation between group and bus
1780 Vrms for 1 minute
bus current requirement
250 mA
maximum power dissipation in W
10.9 W
local signalling
1 LED (green)bus communication is present (Active):
1 LED (red)external fault detected (F):
32 LEDs (green)input status:
marking
CE
module format
Standard
net weight
0.3 kg
Environment
standards
UL 508
CSA C22.2 No 142
product certifications
FM Class 1 Division 2
CUL
resistance to electrostatic discharge
4 kV contact conforming to IEC 801-2
8 kV on air conforming to IEC 801-2
resistance to electromagnetic fields
10 V/m 80…2000 MHz conforming to IEC 801-3
ambient air temperature for operation
0…60 °C
ambient air temperature for storage
-40…85 °C
relative humidity
95 % without condensation
operating altitude
<= 5000 m
Offer Sustainability
Sustainable offer status
Green Premium product
REACh Regulation
EU RoHS Directive
Pro-active compliance (Product out of EU RoHS legal scope)
EU RoHS Declaration
Mercury free
Yes
RoHS exemption information
China RoHS Regulation
Environmental Disclosure
Circularity Profile
WEEE
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Contractual warranty
Warranty
18 months
