discrete output module Modicon Quantum - 16 O - 20..56 V AC

Ülevaaded: 0

Tootekood: 140DAO84220C

Quick Overview

Saadavus: Ei saa enam tellida

576,52 € (ilma KM-ta)

Details

Main
range of product
Modicon Quantum automation platform
product or component type
AC discrete output modules
discrete output number
16
Complementary
group of channels
4 groups of 4 channels
supply frequency
47...63 Hz
maximum voltage drop
1.5 V
discrete output voltage
20...56 V AC
addressing requirement
1 output word
absolute maximum output
100 Vrms 1 cycle AC
63 Vrms for 10 s AC
111 Vrms for 1.3 s AC
maximum load current
16 A rms per module
4 A rms per group
4 A rms 20...56 V per output
surge current
45 A during 1 cycle per group
25 A during 2 cycles per group
30 A during 3 cycles per group
dV/dt
400 V/ms
response time
<= 0.5 ms at state 0 to state 1
<= 0.5 ms at state 1 to state 0
fault indication
Loss of field power
Blown fuse
protection type
Internal output protection by 5 A fuse
Internal by RC filter
power dissipation
1.85 + (1.1 V x total module load current)
marking
CE
local signalling
1 LED (green)bus communication is present (Active):
1 LED (red)external fault detected (F):
16 LEDs (green)input status:
bus current requirement
350 mA
module format
Standard
net weight
0.45 kg
Environment
protective treatment
Conformal coating Humiseal 1A33
product certifications
FM Class 1 Division 2
CUL
standards
UL 508
CSA C22.2 No 142
electromagnetic compatibility
Electrostatic discharge immunity test - test level: 4 kV (contact discharge) conforming to IEC 801-2
Electrostatic discharge immunity test - test level: 8 kV (air discharge) conforming to IEC 801-2
Susceptibility to electromagnetic fields - test level: 10 V/m (80...1000 MHz) conforming to IEC 801-3
ambient air temperature for operation
0…60 °C
ambient air temperature for storage
-40…85 °C
relative humidity
95 % without condensation
operating altitude
<= 5000 m
Contractual warranty
Warranty
18 months
