distributed analog/discrete I/O Modicon Momentum

Ülevaaded: 0

Tootekood: 170ANR12090

Quick Overview

Saadavus: Tellimisel

1 542,43 € (ilma KM-ta)

Details

Main
range of product
Modicon Momentum automation platform
product or component type
Analogue,discrete I/O base
group of channels
1 group of 8 discrete outputs
2 groups of 4 discrete inputs
1 group of 6 analog inputs
1 group of 4 analog outputs
analogue input range
0...10 V
analogue input type
Single ended
analogue input resolution
14 bits 0...10 V
discrete input voltage
24 V DC
analogue output range
0...10 V 14 bits
discrete output voltage
10...30 V
output short-circuit protection
With discrete output
output overload protection
With discrete output
Complementary
discrete input number
8 IEC 1131-2 Type 2
[Us] rated supply voltage
24 V 19,2…30 V)DC
maximum analogue input voltage
15 V
input voltage limits
3...32 V
discrete input logic
Positive
voltage state 0 guaranteed
<= 5 V discrete input
voltage state 1 guaranteed
>= 11 V discrete input
current state 0 guaranteed
<= 2 mA discrete input)
current state 1 guaranteed
>= 6 mA discrete input)
input overvoltage protection
45 V 10 s discrete input
input resistance
1 MOhm analogue input circuit
output load
>= 2 kOhm 0...10 V analogue output
conversion time
0,75 ms analogue input circuit
1,2 ms analogue output
conversion error
+/- 0.4 % 0...10 V 25 °C analogue output
0,002 0...10 V 25 °C analogue input circuit
fail state
Analogue output hold
Analogue output reset to zero
discrete output type
Transistor
discrete output logic
Positive
discrete output current
2 A per group
2 A per module
0.25 A per point
maximum leakage current
0,4 mA DC 30 V discrete output
maximum voltage drop
<0,4 V 0,25 A at state on discrete output
surge current
2,5 A 1 ms discrete output
response time
1.05 ms from state 1 to state 0 discrete output
1.2 ms from state 0 to state 1 discrete input
1.2 ms from state 0 to state 1 discrete output
1.2 ms from state 1 to state 0 discrete input
isolation voltage
500 V 1 min) between analogue I/O and operating voltage
500 V 1 min) between operating voltage and I/O from ground
maximum power dissipation in W
6 W
marking
CE
local signalling
Channel status 4 LEDs
electrical connection
2 connectors for removable terminal blocks
current consumption
400 mA 24 V DC
depth
47,5 mm
height
125 mm
width
141,5 mm
net weight
0,24 kg
Environment
product certifications
UL
CSA
protective treatment
TC
resistance to electrostatic discharge
4 kV contact IEC 801-2
8 kV on air IEC 801-2
resistance to electromagnetic fields
10 V/m 80...1000 MHz IEC 801-3
ambient air temperature for operation
0…60 °C
ambient air temperature for storage
-40…85 °C
relative humidity
95 % without condensation
operating altitude
<= 5000 m
Offer Sustainability
Jätkusuutliku pakkumise olek
Green Premium toode
REACh-määrus
ELi RoHS direktiiv
Ennetav vastavus (toode ei jää EL-i RoHS seadustega määratud piiridesse)
ELi RoHS deklaratsioon
Elavhõbedavaba
Jah
RoHS eranditeave
Hiina EoHS regulatsioon
Keskkonnaalane avaldus
Ringlusprofiil
WEEE
Tootest tuleb Euroopa Liidu turgudel vabaneda vastavuses erijäätmeseadustele ning see ei tohi sattuda olmeprügi sekka.
Contractual warranty
Garantii
18 months
