DLP modular dist chassis 76modules(18mm) insulating material for PLA H750xW500

Details

Main
range	Thalassa
accessory / separate part category	Mounting accessory
Application	Multi-purpose Modular distribution application
product or component type	Chassis
device short name	DLP
For enclosure nominal dimensions	750 mm 500 mm
mounting location	Front of enclosure
range compatibility	Thalassa PLA
device composition	1 chassis structure 4 front panels with 35 mm DIN rail 1 neutral/earth strip 2 x 16 mm² 5 x 6 mm²
additional information	IP2x not respected when chassis is mounted at 67 mm

Complementary
material	Front panel self-extinguishing Chassis structure and rails galvanised steel
colour	Front panel grey RAL 7032)
fixing mode	By fixing element - on front with supports
NULL	In height from 40 to 85 mm DIN rail
number of horizontal rows	4
total number of 18 mm modules	76
type of front plate	Cut-out plate
number of cut-out	4 cut-outs
height	Nominal 750 mm Real 677 mm
width	Nominal 500 mm Real 416 mm
depth	Real 135 mm

Contractual warranty
Garantii	18 months
