double contact block's for head Ø22 1NO+1NC Faston connector

Ülevaaded: 0

Tootekood: ZBE5053

Quick Overview

Saadavus: Ei saa enam tellida

25,13 € (ilma KM-ta)

Details

Main
range of product
Harmony XB4
Harmony XB5
product or component type
Contact block
device short name
ZBE
sale per indivisible quantity
1
IP degree of protection
IP20 conforming to IEC 60529
contacts type and composition
1 NO + 1 NC
contact operation
Slow-break
contact block type
Double
contacts usage
High power switching contacts
connections - terminals
Faston connector, connection size: 1 x 6.35 mm
Faston connector, connection size: 2 x 2.8 mm
Complementary
net weight
0.032 kg
positive opening
With
mechanical durability
10000000 cycles
short-circuit protection
10 A cartridge fuse type gG conforming to EN/IEC 60947-5-1
[Ith] conventional free air thermal current
10 A conforming to EN/IEC 60947-5-1
[Ui] rated insulation voltage
300 V conforming to EN 60947-1
[Uimp] rated impulse withstand voltage
EN 60947-1 6 kV
[Ie] rated operational current
1.1 A at 125 V, DC-13, P300 conforming to EN/IEC 60947-5-1
mounting of block
Front mounting
condition of use
Mounting on push-button collar
electrical composition code
C15 (quantity <= 1)
Environment
ambient air temperature for storage
-40…70 °C
ambient air temperature for operation
-40…70 °C
vibration resistance
5 gn (f= 2…500 Hz) conforming to IEC 60068-2-6
shock resistance
30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27
50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27
Contractual warranty
Warranty
18 months
