Earth-leakage relay RH10P - 300 mA - 48 V

Ülevaaded: 0

Tootekood: 56215

Quick Overview

Saadavus: Ei saa enam tellida

199,17 € (ilma KM-ta)

Details

Main
range
Vigirex
range of product
Vigirex
device short name
RH10P
product or component type
Residual current protection relay
range compatibility
Vigirex RH TOA earth leakage current sensor
Vigirex RH A earth leakage current sensor
relay application
Residual current protection relay
Complementary
earthing system
TN-S
IT
TT
[Us] rated supply voltage
48 V AC 50/60 Hz
power consumption in VA
4 VA
type of measurement
Earth fault current internal measurement 80...100 %
residual earth-leakage time delay adjustment type
Instantaneous 0,3 A
test function
Remote test
Local
monitoring
Electronics continuous)
Power supply continuous)
Relay/sensor link continuous)
[Ithe] conventional enclosed thermal current
8 A
minimum load
10 mA 12 V
net weight
0,3 kg
mechanical robustness
Fire resistance IEC 60695-2-1
IK protection 2 joulesIK07 EN 50102
IP protectionIP20 IEC 60529
IP protectionIP30 IEC 60529
IP protectionIP40 IEC 60529
Vibrations 13.2...100 Hz0.7 g
Vibrations 2...13.2 Hz+/- 1 mm
earth-leakage protection class
Class AC
Class A si
overvoltage category
IV
tamperproof of settings
Protected by sealable cover
mounting support
Panel
height
72 mm
width
72 mm
depth
78 mm
connections - terminals
Auxiliary power supply terminal block 0,2…2,5 mm² flexible AWG 24...AWG 12
Auxiliary power supply terminal block 0,2…2,5 mm² rigid AWG 24...AWG 12
Auxiliary power supply terminal block 0,25…2,5 mm² flexible AWG 24...AWG 12
Fault terminal block 0,2…2,5 mm² flexible AWG 24...AWG 12
Fault terminal block 0,2…2,5 mm² rigid AWG 24...AWG 12
Fault terminal block 0,25…2,5 mm² flexible AWG 24...AWG 12
Relay test and fault reset terminal block 0,2…2,5 mm² flexible AWG 24...AWG 12
Relay test and fault reset terminal block 0,2…2,5 mm² rigid AWG 24...AWG 12
Relay test and fault reset terminal block 0,25…2,5 mm² flexible AWG 24...AWG 12
Sensor terminal block 0,2…2,5 mm² flexible AWG 24...AWG 12
Sensor terminal block 0,2…2,5 mm² rigid AWG 24...AWG 12
Sensor terminal block 0,25…2,5 mm² flexible AWG 24...AWG 12
Voltage presence terminal block 0,2…2,5 mm² flexible AWG 24...AWG 12
Voltage presence terminal block 0,2…2,5 mm² rigid AWG 24...AWG 12
Voltage presence terminal block 0,25…2,5 mm² flexible AWG 24...AWG 12
wire stripping length
Auxiliary power supply 7 mm
Fault 7 mm
Relay test and fault reset 7 mm
Sensor 7 mm
Voltage presence 7 mm
tightening torque
Auxiliary power supply 0,6 N.m
Fault 0,6 N.m
Relay test and fault reset 0,6 N.m
Sensor 0,6 N.m
Voltage presence 0,6 N.m
Environment
ambient air temperature for operation
-35…70 °C
ambient air temperature for storage
-55…85 °C
electromagnetic compatibility
Conducted and radiated emissionsB CISPR 11
Conducted radio-frequency immunity test3 IEC 61000-4-6
Electrostatic discharge immunity test4 IEC 61000-4-2
High-energy conducted susceptibility4 IEC 61000-4-5
Low-energy conducted susceptibility4 IEC 61000-4-4
Radiated susceptibility3 IEC 61000-4-3
electrical shock protection class
Class II
Contractual warranty
Garantii
18 months
