Abikontaktplokk, TeSys D, 2NO + 2NC, esikinnitus, kruvikinnitusklemmid, EN 50012

Tootekood: LADN22G

Quick Overview

Saadavus: Tellimisel

9,22 € (ilma KM-ta)

Qty:

Details

Main
range of product	TeSys D
range	TeSys
device short name	LADN
product or component type	Auxiliary contact block
range compatibility	TeSys LC1D09...D80 TeSys LC1DT20...DT40 TeSys LC1DT60A...DT80A TeSys LC1F TeSys CR1F
auxiliary contacts operation	Instantaneous
pole contact composition	2 NO + 2 NC
connections - terminals	screw clamp terminals 1 1…2,5 mm²flexible with cable end screw clamp terminals 1 1…2,5 mm²flexible without cable end screw clamp terminals 2 1…2,5 mm²flexible with cable end screw clamp terminals 2 1…2,5 mm²flexible without cable end screw clamp terminals 1 1…2,5 mm²solid screw clamp terminals 2 1…2,5 mm²solid

Complementary
mounting location	Front
[Ui] rated insulation voltage	690 V IEC 60947-5-1 600 V CSA 600 V UL
[Ue] rated operational voltage	690 V AC 25...400 Hz
[Ith] conventional free air thermal current	10 A 60 °C
Irms rated making capacity	140 A AC IEC 60947-5-1 250 A DC IEC 60947-5-1
permissible short-time rating	100 A 60 °C 1 s 120 A 60 °C 500 ms 140 A 60 °C 100 ms
protection type	GG fuse 10 A
mechanical durability	30 Mcycles
minimum switching current	5 mA
minimum switching voltage	17 V
non-overlap time	1,5 ms on de-energisation no overlap between NC and NO contact 1,5 ms on energisation no overlap between NC and NO contact
insulation resistance	> 10 MOhm
tightening torque	1,7 N.m
net weight	0,05 kg

Environment
environmental characteristic	Normal environment
standards	EN/IEC 60947-5-1 UL 60947-5-1 CSA C22.2 No 60947-5-1 GB/T 14048.5 EN 50012
product certifications	IECEE CB Scheme UL CSA CCC EAC
IP degree of protection	IP20 IEC 60529
protective treatment	TH IEC 60068
ambient air temperature for operation	-5…60 °C
ambient air temperature for storage	-60…80 °C
operating altitude	3000 m

Offer Sustainability
Jätkusuutliku pakkumise olek	Green Premium toode
REACh-määrus	REACh-deklaratsioon
Ilma SVHC REACh-ta	Jah
ELi RoHS direktiiv	Vastavus ELi RoHS deklaratsioon
Mürgiste raskemetallideta	Jah
Elavhõbedavaba	Jah
RoHS eranditeave	Jah
Hiina EoHS regulatsioon	Hiina RoHS deklaratsioon Ennetav Hiina RoHS deklaratsioon (ei kuulu Hiina RoHS-i õigussfääri)
Keskkonnaalane avaldus	Toote keskkonnaprofiil
WEEE	Tootest tuleb Euroopa Liidu turgudel vabaneda vastavuses erijäätmeseadustele ning see ei tohi sattuda olmeprügi sekka.

Contractual warranty
Garantii	18 months
