Abikontaktplokk, TeSys D, 2NO + 2NC, esikinnitus, vedruklemmid

Ülevaaded: 0

Tootekood: LADN223

Quick Overview

Saadavus: Tellimisel

44,85 € (ilma KM-ta)

Details

Main
range of product
TeSys D
range
TeSys
device short name
LADN
product or component type
Auxiliary contact block
range compatibility
TeSys CAD
TeSys LC1D
auxiliary contacts operation
Instantaneous
pole contact composition
2 NO + 2 NC
connections - terminals
spring terminals 2 2,5 mm²flexible without cable end
spring terminals 2 2,5 mm²solid
Complementary
mounting location
Front
[Ui] rated insulation voltage
690 V IEC 60947-5-1
600 V CSA
600 V UL
[Ue] rated operational voltage
690 V AC 25...400 Hz
[Ith] conventional free air thermal current
10 A 60 °C
Irms rated making capacity
140 A AC IEC 60947-5-1
250 A DC IEC 60947-5-1
permissible short-time rating
100 A 60 °C 1 s
120 A 60 °C 500 ms
140 A 60 °C 100 ms
protection type
GG fuse 10 A
mechanical durability
30 Mcycles
minimum switching current
5 mA
minimum switching voltage
17 V
non-overlap time
1,5 ms on de-energisation no overlap between NC and NO contact
1,5 ms on energisation no overlap between NC and NO contact
insulation resistance
> 10 MOhm
net weight
0,05 kg
Environment
environmental characteristic
Normal environment
standards
EN/IEC 60947-5-1
UL 60947-5-1
CSA C22.2 No 60947-5-1
GB/T 14048.5
product certifications
IECEE CB Scheme
UL
CSA
CCC
EAC
IP degree of protection
IP20 IEC 60529
protective treatment
TH IEC 60068
ambient air temperature for operation
-5…60 °C
ambient air temperature for storage
-60…80 °C
operating altitude
3000 m
Offer Sustainability
Jätkusuutliku pakkumise olek
Green Premium toode
REACh-määrus
Ilma SVHC REACh-ta
Jah
ELi RoHS direktiiv
Mürgiste raskemetallideta
Jah
Elavhõbedavaba
Jah
RoHS eranditeave
Hiina EoHS regulatsioon
Hiina RoHS deklaratsioon
Ennetav Hiina RoHS deklaratsioon (ei kuulu Hiina RoHS-i õigussfääri)
Keskkonnaalane avaldus
WEEE
Tootest tuleb Euroopa Liidu turgudel vabaneda vastavuses erijäätmeseadustele ning see ei tohi sattuda olmeprügi sekka.
Contractual warranty
Garantii
18 months
