Termilise ülekoormuse releed TeSys LRD | 17...25A, klass 10A

Tootekood: LR3D325

Quick Overview

Saadavus: Tellimisel

53,38 € (ilma KM-ta)

Qty:

Details

Main
range	TeSys
product name	TeSys LRD
product or component type	Non differential thermal overload relay
device short name	LR3D
relay application	Motor protection
product compatibility	LC1D50A LC1D40A LC1D65A
network type	DC AC
thermal protection adjustment range	17…25 A
[Ui] rated insulation voltage	Power circuit 600 V CSA Power circuit 600 V UL Power circuit 690 V IEC 60947-4-1

Complementary
network frequency	0...400 Hz
mounting support	Plate, with specific accessories Rail, with specific accessories Under contactor
tripping threshold	1.14 +/- 0.06 Ir IEC 60947-4-1
[Ith] conventional free air thermal current	5 A signalling circuit
permissible current	0,95 A 380 V AC-15 signalling circuit 0,06 A 440 V DC-13 signalling circuit
[Ue] rated operational voltage	690 V AC 0...400 Hz
[Uimp] rated impulse withstand voltage	6 kV
phase failure sensitivity	Tripping current 130 % of Ir on two phase, the last one at 0
control type	Red push-button stop Blue push-button reset
temperature compensation	-20…60 °C
connections - terminals	Control circuit screw clamp terminals 2 1…2,5 mm² flexible without cable end Control circuit screw clamp terminals 2 1…2,5 mm² flexible with cable end Control circuit screw clamp terminals 2 1…2,5 mm² solid without cable end Power circuit EverLink BTR screw connectors 1 1…35 mm² flexible without cable end Power circuit EverLink BTR screw connectors 1 1…35 mm² flexible with cable end Power circuit EverLink BTR screw connectors 1 1…35 mm² solid without cable end
tightening torque	Control circuit 1,7 N.m screw clamp terminals Power circuit 5 N.m EverLink BTR screw connectors
height	70 mm
width	55 mm
depth	123 mm
net weight	0,375 kg

Environment
protective treatment	TH IEC 60068
IP degree of protection	IP20 IEC 60529
ambient air temperature for operation	-20…60 °C without derating IEC 60947-4-1
ambient air temperature for storage	-60…70 °C
flame retardance	V1 UL 94
mechanical robustness	Shocks15 Gn for 11 ms IEC 60068-2-7 Vibrations4 gn IEC 60068-2-6
dielectric strength	6 kV 50 Hz IEC 60255-5
standards	IEC 60947-5-1 EN 60947-5-1 UL 508 EN 60947-4-1 IEC 60947-4-1 CSA C22.2 No 14 ATEX D 94/9/CE
product certifications	GOST DNV ATEX INERIS LROS (Lloyds register of shipping) GL CSA UL BV RINA CCC

Offer Sustainability
Jätkusuutliku pakkumise olek	Green Premium toode
Ilma SVHC REACh-ta	Jah
ELi RoHS direktiiv	Vastavus ELi RoHS deklaratsioon
Mürgiste raskemetallideta	Jah
Elavhõbedavaba	Jah
RoHS eranditeave	Jah
Hiina EoHS regulatsioon	Hiina RoHS deklaratsioon
Keskkonnaalane avaldus	Toote keskkonnaprofiil
Ringlusprofiil	Kasutuselt kõrvaldamise teave
WEEE	Tootest tuleb Euroopa Liidu turgudel vabaneda vastavuses erijäätmeseadustele ning see ei tohi sattuda olmeprügi sekka.

Contractual warranty
Garantii	18 months
