Termilise ülekoormuse releed TeSys LRD | 4...6A, klass 10A

Ülevaaded: 0

Tootekood: LRD106

Quick Overview

Saadavus: Tellimisel

53,34 € (ilma KM-ta)

Details

Main
range
TeSys
product name
TeSys LRD
product or component type
Differential thermal overload relay
device short name
LRD
relay application
Motor protection
product compatibility
LC1D32
LC1D18
LC1D25
LC1D12
LC1D09
LC1D38
network type
AC
DC
thermal protection adjustment range
4…6 A
[Ui] rated insulation voltage
Power circuit 600 V CSA
Power circuit 600 V UL
Power circuit 690 V IEC 60947-4-1
Complementary
network frequency
0...400 Hz
mounting support
Plate, with specific accessories
Rail, with specific accessories
Under contactor
tripping threshold
1.14 +/- 0.06 Ir IEC 60947-4-1
[Ith] conventional free air thermal current
5 A signalling circuit
permissible current
3 A 120 V AC-15 signalling circuit
0,22 A 125 V DC-13 signalling circuit
[Ue] rated operational voltage
690 V AC 0...400 Hz
[Uimp] rated impulse withstand voltage
6 kV
phase failure sensitivity
Tripping current 130 % of Ir on two phase, the last one at 0
control type
Red push-button stop
Blue push-button reset
temperature compensation
-20…60 °C
connection pitch
14,5 mm
connections - terminals
Control circuit screw clamp terminals 2 1…2,5 mm² flexible without cable end
Control circuit screw clamp terminals 2 1…2,5 mm² flexible with cable end
Control circuit screw clamp terminals 2 1…2,5 mm² solid without cable end
Power circuit lugs-ring terminals
tightening torque
Control circuit 1,7 N.m screw clamp terminals
Power circuit 2,3 N.m lugs-ring terminals M4
width
45 mm
depth
70 mm
net weight
0,124 kg
Environment
protective treatment
TH IEC 60068
IP degree of protection
IP20 IEC 60529
ambient air temperature for operation
-20…60 °C without derating IEC 60947-4-1
ambient air temperature for storage
-60…70 °C
flame retardance
V1 UL 94
mechanical robustness
Vibrations6 Gn IEC 60068-2-6
Shocks15 Gn for 11 ms IEC 60068-2-7
dielectric strength
6 kV 50 Hz IEC 60255-5
standards
ATEX D 94/9/CE
UL 508
IEC 60947-4-1
IEC 60947-5-1
EN 60947-4-1
CSA C22.2 No 14
EN 60947-5-1
product certifications
ATEX INERIS
UL
RINA
LROS (Lloyds register of shipping)
BV
GL
CCC
DNV
CSA
GOST
Offer Sustainability
Jätkusuutliku pakkumise olek
Green Premium toode
REACh-määrus
Ilma SVHC REACh-ta
Jah
ELi RoHS direktiiv
Elavhõbedavaba
Jah
RoHS eranditeave
Hiina EoHS regulatsioon
Hiina RoHS deklaratsioon
Toode ei kuulu Hiina RoHS sfääri. Ainedeklaratsioon teavitamiseks.
Keskkonnaalane avaldus
Ringlusprofiil
Contractual warranty
Garantii
18 months
