TeSys SK - abikontaktplokk - 1 NO + 1 NC

Tootekood: LA1SK11

Quick Overview

Saadavus: Tellimisel

8,03 € (ilma KM-ta)

Qty:

Details

Main
range	TeSys
device short name	LA1SK
product or component type	Auxiliary contact block
product compatibility	LC1SK
auxiliary contacts operation	Instantaneous
pole contact composition	1 NO + 1 NC
connections - terminals	screw clamp terminals 1 1,5…6 mm²solid screw clamp terminals 2 1,5…4 mm²solid screw clamp terminals 1 0,5…6 mm²flexible with cable end screw clamp terminals 2 0,35…2,5 mm²flexible with cable end screw clamp terminals 1 0,35…6 mm²flexible without cable end screw clamp terminals 2 0,35…1,5 mm²flexible without cable end

Complementary
mounting location	Front side
[Ui] rated insulation voltage	690 V IEC 60947 690 V BS 5424 690 V VDE 0110 group C 690 V CSA C22.2 No 14
[Ue] rated operational voltage	690 V AC <= 400 Hz
[Ith] conventional free air thermal current	10 A 55 °C
associated fuse rating	10 A gL IEC 60947 10 A gL VDE 0660
tightening torque	0,8 N.m screw clamp terminals
width	27 mm
net weight	0,022 kg

Environment
standards	VDE 0660 BS 5424 IEC 60947 NF C 63-110
product certifications	CSA UL
IP degree of protection	IP2x
protective treatment	TC IEC 60068
ambient air temperature for operation	-20…50 °C
ambient air temperature for storage	-50…70 °C
operating altitude	2000 m without

Offer Sustainability
Jätkusuutliku pakkumise olek	Green Premium toode
ELi RoHS direktiiv	Vastavus ELi RoHS deklaratsioon
Elavhõbedavaba	Jah
RoHS eranditeave	Jah
Hiina EoHS regulatsioon	Hiina RoHS deklaratsioon Toode ei kuulu Hiina RoHS sfääri. Ainedeklaratsioon teavitamiseks.
Keskkonnaalane avaldus	Toote keskkonnaprofiil
WEEE	Tootest tuleb Euroopa Liidu turgudel vabaneda vastavuses erijäätmeseadustele ning see ei tohi sattuda olmeprügi sekka.

Contractual warranty
Garantii	18 months
