Starter TeSys H 3kW-400V juhtimine 24VDC

Ülevaaded: 0

Tootekood: LZ1H6X5BD

Quick Overview

Saadavus: Tellimisel

125,23 € (ilma KM-ta)

Details

Main
range
TeSys
product name
TeSys H
device short name
LZ1H
product or component type
Ultra-compact starter
motor starter type
Direct on line
poles description
3P
[Ue] rated operational voltage
500 V AC
[Ie] rated operational current
6.5 A at 500 V AC-53A
9 A at 500 V AC-51
5 A at 500 V AC-53A mounting side by side
7 A at 500 V AC-51 mounting side by side
thermal protection adjustment range
1.5…9 A
motor power kW
1.5 kW at 220 V AC 0.65
1.5 kW at 230 V AC 0.65
2.2 kW at 380 V AC 0.65
3 kW at 400 V AC 0.65
3 kW at 415 V AC 0.65
3 kW at 440 V AC 0.65
3 kW at 500 V AC 0.65
motor power hp
1 hp at 200 V AC
1.5 hp at 230 V AC
3 hp at 460 V AC
[Uc] control circuit voltage
24 V DC
thermal overload class
Class 10A conforming to IEC 60947-4-2
Complementary
auxiliary contact composition
1 C/O fault signalling
control circuit voltage limits
19.2...30 V DC
current consumption
<= 40 mA at 24 V DC
reset
Manual
Automatic reset
Electrical reset
Electrical durability
30 Mcycles
maximum operating rate
120 cyc/mn AC-51 50 % ON
6 cyc/mn AC-53A 50 % ON
mounting mode
By clips
mounting support
DIN rail
connections - terminals
Screw clamp terminals 1 cable(s) 0.2…2.5 mm² - rigid
Screw clamp terminals 1 cable(s) 0.25…2.5 mm² - flexible - with cable end
Screw clamp terminals 1 cable(s) 0.2…2.5 mm² - flexible - without cable end
tightening torque
0.5…0.6 N.m flat Ø 2.5 mm screwdriver 3 mm
certifications
CULus
CE
standards
IEC 60947-4-2
UL 60947-4-1
[Ui] rated insulation voltage
500 V AC 50/60 Hz
[Uimp] rated impulse withstand voltage
6 kV
pollution degree
2
width
22.5 mm
height
99 mm
depth
114.5 mm
net weight
212 g
Environment
IP degree of protection
IP20
protective treatment
TC
ambient air temperature for operation
-25…30 °C without derating
30…70 °C with derating
ambient air temperature for storage
-40…80 °C
Offer Sustainability
Sustainable offer status
Green Premium product
REACh free of SVHC
Yes
EU RoHS Directive
Toxic heavy metal free
Yes
Mercury free
Yes
RoHS exemption information
China RoHS Regulation
Environmental Disclosure
Circularity Profile
WEEE
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
