analog input module X80 - 4 inputs - high speed

Ülevaaded: 0

Tootekood: BMXAMI0410

Quick Overview

Saadavus: Tellimisel

591,62 € (ilma KM-ta)

Details

Main
range of product
Modicon X80
product or component type
Analog input module
electrical connection
20 ways 1 connector
Isolation between channels
Isolated
input level
High level
analogue input number
4
analogue input type
Current +/- 20 mA
Current 0...20 mA
Current 4...20 mA
Voltage +/- 10 V
Voltage +/- 5 V
Voltage 0...10 V
Voltage 0...5 V
Voltage 1...5 V
Complementary
analog/digital conversion
24 bits
analogue input resolution
16 bits
input impedance
10 MOhm
permitted overload on inputs
+/- 30 V +/- 10 V
+/- 30 V +/- 5 V
+/- 30 V 0...10 V
+/- 30 V 0...5 V
+/- 30 V 1...5 V
+/- 90 mA +/- 20 mA
+/- 90 mA 0...20 mA
+/- 90 mA 4...20 mA
internal conversion resistor
250 Ohm
precision of internal conversion resistor
0.1 % - 15 ppm/°C
type of filter
First order digital filtering
fast read cycle time
1 ms + 1 ms x number of channels used
nominal read cycle time
5 ms for 4 channels
measurement error
<= 0.1 % of full scale +/- 10 V 0...60 °C
<= 0.1 % of full scale +/- 5 V 0...60 °C
<= 0.1 % of full scale 0...10 V 0...60 °C
<= 0.1 % of full scale 0...5 V 0...60 °C
<= 0.1 % of full scale 1...5 V 0...60 °C
<= 0.3 % of full scale +/- 20 mA 0...60 °C
<= 0.3 % of full scale 0...20 mA 0...60 °C
<= 0.3 % of full scale 4...20 mA 0...60 °C
0.075 % of full scale +/- 10 V 25 °C
0.075 % of full scale +/- 5 V 25 °C
0.075 % of full scale 0...10 V 25 °C
0.075 % of full scale 0...5 V 25 °C
0.075 % of full scale 1...5 V 25 °C
0.15 % of full scale +/- 20 mA 25 °C
0.15 % of full scale 0...20 mA 25 °C
0.15 % of full scale 4...20 mA 25 °C
temperature drift
15 ppm/°C +/- 10 V
15 ppm/°C +/- 5 V
15 ppm/°C 0...10 V
15 ppm/°C 0...5 V
15 ppm/°C 1...5 V
30 ppm/°C +/- 20 mA
30 ppm/°C 0...20 mA
30 ppm/°C 4...20 mA
recalibration
Internal
common mode between channels
>= 80 dB
digital value format
+/- 32767 in user scale
+/- 10000 by default
isolation voltage
300 V DC between channels
1400 V DC between channels and ground
1400 V DC between channels and bus
measurement resolution
0.35 mV +/- 10 V
0.35 mV +/- 5 V
0.35 mV 0...10 V
0.35 mV 0...5 V
0.35 mV 1...5 V
0.92 µA +/- 20 mA
0.92 µA 0...20 mA
0.92 µA 4...20 mA
maximum conversion value
+/- 11.4 V +/- 10 V
+/- 11.4 V +/- 5 V
+/- 11.4 V 0...10 V
+/- 11.4 V 0...5 V
+/- 11.4 V 1...5 V
0...30 mA +/- 20 mA
0...30 mA 0...20 mA
0...30 mA 4...20 mA
protective treatment
TC
operating altitude
0...2000 m
2000...5000 m with derating factor
status LED
RUN 1 LED green)
Channel diagnostic 1 LED per channel green)
ERR 1 LED red)
I/O 1 LED red)
net weight
0,143 kg
power consumption in W
0,82 W 24 V DC typical
1,30 W 24 V DC maximum
Environment
vibration resistance
3 gn
shock resistance
30 gn
ambient air temperature for storage
-40…85 °C
ambient air temperature for operation
0…60 °C
relative humidity
5…95 % 55 °C without condensation
IP degree of protection
IP20
directives
2014/35/EU - low voltage directive
2014/30/EU - electromagnetic compatibility
2012/19/EU - WEEE directive
product certifications
RCM
EAC
Merchant Navy
UL
CSA
CE
standards
EN 61131-2
EN 61000-6-4
EN 61000-6-2
EN 61010-2-201
Offer Sustainability
Jätkusuutliku pakkumise olek
Green Premium toode
REACh-määrus
ELi RoHS direktiiv
Ennetav vastavus (toode ei jää EL-i RoHS seadustega määratud piiridesse)
ELi RoHS deklaratsioon
Elavhõbedavaba
Jah
RoHS eranditeave
Hiina EoHS regulatsioon
Keskkonnaalane avaldus
Ringlusprofiil
WEEE
Tootest tuleb Euroopa Liidu turgudel vabaneda vastavuses erijäätmeseadustele ning see ei tohi sattuda olmeprügi sekka.
Contractual warranty
Garantii
18 months
