compact I/O expansion block TM5 - 8 AI - 8 AO - 0-10 V - 4-20 mA - 12 bits

Ülevaaded: 0

Tootekood: TM5CAI8O8CVL

Quick Overview

Saadavus: Tellimisel

1 250,38 € (ilma KM-ta)

Details

Main
range of product
Modicon TM5
product or component type
Compact I/O expansion block
enclosure material
Plastic
colour
White
input/output number
16
input/output number of splitter box
8 I + 8 O
number of modules
Analog input: 2 module(s) x 4
Analog output: 2 module(s) x 4
analogue input number
8
analogue input range
4...20 mA
0...20 mA
+/- 10 V
analogue input resolution
12 bits for current
11 bits + sign for voltage
analogue output number
8
analogue output type
Voltage 4
Current 4
analogue output range
0...20 mA
+/- 10 V
Complementary
input filtering
<= 50 ms not configurable
sampling duration
20 ms input/output for the whole module
5 ms input/output per channel
response time
<= 1 ms status change for output
maximum leakage current
5 µA (when switched off) for output
protection type
Short-circuit for output
isolation
500 Vrms AC insulation between channel and bus
No insulation between channels
current consumption
8 mA at 5 V DC bus
217 mA at 24 V DC input/output
power dissipation in W
5.25 W
local signalling
4 LEDs (green)power supply:
4 LEDs (red)power supply:
8 LEDs (yellow)output status:
8 LEDs (green)input status:
electrical connection
Removable spring terminal block
surge withstand
0.5 kV differential mode 24 V DC conforming to EN/IEC 61000-4-5
1 kV common mode 24 V DC conforming to EN/IEC 61000-4-5
mounting support
DIN rail
net weight
0.25 kg
Environment
standards
CSA C22.2 No 213
UL 508
CSA C22.2 No 142
IEC 61131-2
product certifications
C-Tick
UL
GOST-R
CSA
marking
CE
ambient air temperature for operation
-10…50 °C (vertical installation)
-10…60 °C (horizontal installation)
ambient air temperature for storage
-40…70 °C
relative humidity
5…95 % without condensation
IP degree of protection
IP20 conforming to IEC 61131-2
pollution degree
2 conforming to IEC 60664
operating altitude
0...2000 m
storage altitude
0…3000 m
vibration resistance
1 gn at 8.4…150 Hz on DIN rail
3.5 mm at 5…8.4 Hz on DIN rail
shock resistance
15 gn for 11 ms
resistance to electrostatic discharge
4 kV on contact conforming to EN/IEC 61000-4-2
8 kV in air conforming to EN/IEC 61000-4-2
resistance to electromagnetic fields
1 V/m 2...2.7 GHz conforming to EN/IEC 61000-4-3
10 V/m 80...2000 MHz conforming to EN/IEC 61000-4-3
resistance to fast transients
1 kV (I/O) conforming to EN/IEC 61000-4-4
1 kV (shielded cable) conforming to EN/IEC 61000-4-4
2 kV (power lines) conforming to EN/IEC 61000-4-4
electromagnetic compatibility
EN/IEC 61000-4-6
disturbance radiated/conducted
CISPR 11 zone B - class A
Offer Sustainability
Sustainable offer status
Green Premium product
REACh Regulation
REACh free of SVHC
Yes
EU RoHS Directive
Pro-active compliance (Product out of EU RoHS legal scope)
EU RoHS Declaration
Toxic heavy metal free
Yes
Mercury free
Yes
RoHS exemption information
China RoHS Regulation
Environmental Disclosure
Circularity Profile
WEEE
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Contractual warranty
Warranty
18 months
