Details
Characteristics
| range of product | Modicon TM5 | |
|---|---|---|
| product or component type | Discrete input module | |
| discrete input number | 2 | |
| discrete input voltage | 100...240 V |
| range compatibility | Modicon LMC058PacDrive LMC motion controllerModicon M258 | |
|---|---|---|
| product compatibility | PacDrive LMC ProMotion controllerPacDrive LMC Pro 2Logic controllerPacDrive LMC Eco | |
| discrete input voltage type | AC | |
| input voltage limits | 100...240 V | |
| discrete input current | 5…11 mA | |
| colour | Black | |
| input filtering | <= 25 ms configurable by software<= 30 ms hardware from state 1 to state 0<= 40 ms hardware from state 0 to state 1 | |
| protection type | Short-circuit protection | |
| isolation | No insulation between channels2500 V AC insulation between channel and bus for 1 minute | |
| maximum voltage drop | <2 V at 500 mA for sensor supply | |
| maximum supply current for sensors | 500 mA | |
| current consumption | 28 mA at 5 V DC bus | |
| maximum power dissipation in W | 0.69 W | |
| local signalling | 1 LED green for power supply1 LED red for power supply2 LEDs green for input status | |
| electrical connection | 3 wires | |
| marking | CE | |
| net weight | 0.025 kg |
| standards | UL 508CSA C22.2 No 142CSA C22.2 No 213IEC 61131-2 | |
|---|---|---|
| product certifications | GOST-RCSAC-TickCULus | |
| ambient air temperature for operation | -10…55 °C without (horizontal installation)-10…60 °C with derating factor (horizontal installation)-10…50 °C (vertical installation) | |
| ambient air temperature for storage | -40…70 °C | |
| relative humidity | 5…95 % without condensation | |
| IP degree of protection | IP20 conforming to IEC 61131-2 | |
| pollution degree | 2 conforming to IEC 60664 | |
| operating altitude | 0...2000 m | |
| storage altitude | 0…3000 m | |
| vibration resistance | 1 gn at 8.4…150 Hz on DIN rail3.5 mm at 5…8.4 Hz on DIN rail | |
| shock resistance | 15 gn for 11 ms | |
| electromagnetic compatibility | Electrostatic discharge immunity test, 4 kV on contact conforming to EN/IEC 61000-4-2Electrostatic discharge immunity test, 8 kV in air conforming to EN/IEC 61000-4-2Susceptibility to electromagnetic fields, 1 V/m 2...2.7 GHz conforming to EN/IEC 61000-4-3Susceptibility to electromagnetic fields, 10 V/m 80...2000 MHz conforming to EN/IEC 61000-4-3Electrical fast transient/burst immunity test, 1 kV I/O conforming to EN/IEC 61000-4-4Electrical fast transient/burst immunity test, 1 kV shielded cable conforming to EN/IEC 61000-4-4Electrical fast transient/burst immunity test, 2 kV power lines conforming to EN/IEC 61000-4-41.2/50 µs shock waves immunity test, 0.5 kV differential mode conforming to EN/IEC 61000-4-51.2/50 µs shock waves immunity test, 1 kV common mode conforming to EN/IEC 61000-4-5Conducted RF disturbances conforming to EN/IEC 61000-4-6Conducted and radiated emissions conforming to CISPR 11 |
| Sustainable offer status | Green Premium product | |
|---|---|---|
| REACh Regulation | ||
| REACh free of SVHC | Yes | |
| EU RoHS Directive | Pro-active compliance (Product out of EU RoHS legal scope) EU RoHS Declaration | |
| Toxic heavy metal free | Yes | |
| Mercury free | Yes | |
| RoHS exemption information | ||
| China RoHS Regulation | ||
| Environmental Disclosure | ||
| Circularity Profile | ||
| WEEE | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins |
| Warranty | 18 months |
|---|
