discrete input module X80 - 16 inputs - 125 V DC

Ülevaaded: 0

Tootekood: BMXDDI1604T

Quick Overview

Saadavus: Tellimisel

622,39 € (ilma KM-ta)

Details

Main
range of product
Modicon X80
product or component type
Discrete input module
product specific application
Extended temperature
discrete input number
16
discrete input type
Isolated
input type
Current sink (logic positive)
discrete input voltage
125 V DC positive
discrete input current
2,4 mA
input compatibility
With 2-wire/3-wire proximity sensors IEC 60947-5-2
Complementary
sensor power supply
88…150 V
voltage state 1 guaranteed
>= 88 V
current state 1 guaranteed
>= 2 mA
voltage state 0 guaranteed
<= 36 V
current state 0 guaranteed
<= 0.5 mA
input impedance
50000 Ohm
insulation resistance
> 10 MOhm 500 V DC
maximum power dissipation in W
8,5 W
DC typical filtering time
5 ms
DC maximum filtering time
9 ms
response time on output
8...30 ms on appearance
paralleling of inputs
Yes
typical current consumption
76 mA 3.3 V DC
current consumption
<= 107 mA 3.3 V DC
protection type
reverse polarity protection fast blow
1 external fuse per group of channel 0,5 A
voltage detection threshold
< 80 V DC sensor fault
> 100 V DC sensor OK
status LED
Module operating (RUN) 1 LED green)
Channel diagnostic 1 LED per channel green)
Module error (ERR) 1 LED red)
Module I/O 1 LED red)
net weight
0,115 kg
Environment
IP degree of protection
IP20
directives
2014/35/EU - low voltage directive
2014/30/EU - electromagnetic compatibility
2012/19/EU - WEEE directive
product certifications
CSA
EAC
Merchant Navy
RCM
CE
UL
standards
EN 61131-2
EN 61000-6-4
EN 61000-6-2
EN 61010-2-201
dielectric strength
2500 V AC 50/60 Hz 1 minute, primary/secondary
vibration resistance
3 gn
shock resistance
30 gn
ambient air temperature for storage
-40…85 °C
ambient air temperature for operation
-25…70 °C
relative humidity
5…95 % 55 °C without condensation
protective treatment
Conformal coating
environmental characteristic
Gas resistant class Gx
Gas resistant class 3C4
Dust resistant class 3S4
Sand resistant class 3S4
Salt resistant level 2
Mold growth resistant class 3B2
Fungal spore resistant class 3B2
operating altitude
0...2000 m
2000...5000 m with derating factor
Offer Sustainability
Jätkusuutliku pakkumise olek
Green Premium toode
REACh-määrus
ELi RoHS direktiiv
Ennetav vastavus (toode ei jää EL-i RoHS seadustega määratud piiridesse)
ELi RoHS deklaratsioon
Elavhõbedavaba
Jah
RoHS eranditeave
Hiina EoHS regulatsioon
Keskkonnaalane avaldus
Ringlusprofiil
WEEE
Tootest tuleb Euroopa Liidu turgudel vabaneda vastavuses erijäätmeseadustele ning see ei tohi sattuda olmeprügi sekka.
Contractual warranty
Garantii
18 months
