isolated analog output module X80 - 4 outputs - for severe environment

Ülevaaded: 0

Tootekood: BMXAMO0410H

Quick Overview

Saadavus: Tellimisel

1 431,81 € (ilma KM-ta)

Details

Main
range of product
Modicon X80
product or component type
Analog output module
product specific application
For severe environments
electrical connection
20 ways 1 connector
Isolation between channels
Isolated
Complementary
measurement error
0.1 % of full scale 25 °C
<= 0.45 % of full scale - 25...70 °C
temperature drift
45 ppm/°C +/- 10 V
45 ppm/°C 0...20 mA
45 ppm/°C 4...20 mA
common mode between channels
>= 80 dB
isolation voltage
1400 V DC between channels and ground
1400 V DC between channels and bus
750 V DC between channels
detection type
Open circuit 0...20 mA
Open circuit 4...20 mA
Short circuit +/- 10 V
load impedance ohmic
>= 1000 Ohm +/- 10 V
<= 500 Ohm 0...20 mA
<= 500 Ohm 4...20 mA
output level
High level
analogue output number
4
analogue output type
Current 0...20 mA
Current 4...20 mA
Voltage +/- 10 V
analogue output resolution
15 bits + sign
supply
Internal power supply via rack
conversion time
<= 1 ms
maximum conversion value
0...21 mA 0...20 mA
0...21 mA 4...20 mA
+/- 10.5 V +/- 10 V
fallback mode
Configurable
Predefined
protective treatment
Conformal coating
operating altitude
0...2000 m
2000...5000 m with derating factor
status LED
RUN 1 LED green)
Channel diagnostic 1 LED per channel green)
ERR 1 LED red)
I/O 1 LED red)
net weight
0,15 kg
power consumption in W
3 W 24 V DC typical
3,2 W 24 V DC maximum
0,48 W 3.3 V DC typical
0,61 W 3.3 V DC maximum
Environment
vibration resistance
3 gn
shock resistance
30 gn
ambient air temperature for storage
-40…85 °C
ambient air temperature for operation
-25…70 °C
relative humidity
5…95 % 55 °C without condensation
IP degree of protection
IP20
directives
2014/35/EU - low voltage directive
2014/30/EU - electromagnetic compatibility
2012/19/EU - WEEE directive
product certifications
IEC-Ex
CSA
RCM
UL
Merchant Navy
CE
EAC
ATEX
standards
EN 61131-2
EN 61000-6-4
EN 61000-6-2
EN 61010-2-201
environmental characteristic
Gas resistant class Gx
Gas resistant class 3C4
Dust resistant class 3S4
Sand resistant class 3S4
Salt resistant level 2
Mold growth resistant class 3B2
Fungal spore resistant class 3B2
Offer Sustainability
Jätkusuutliku pakkumise olek
Green Premium toode
REACh-määrus
ELi RoHS direktiiv
Ennetav vastavus (toode ei jää EL-i RoHS seadustega määratud piiridesse)
ELi RoHS deklaratsioon
Elavhõbedavaba
Jah
RoHS eranditeave
Hiina EoHS regulatsioon
Keskkonnaalane avaldus
Ringlusprofiil
WEEE
Tootest tuleb Euroopa Liidu turgudel vabaneda vastavuses erijäätmeseadustele ning see ei tohi sattuda olmeprügi sekka.
Contractual warranty
Garantii
18 months
