iEM3250 energy meter - CT - Modbus

Previous

analog ammeter scale - 0..75 A

PM5111 Meter, modbus, up to 15th H, 1DO 33 alarms, MID

Ülevaaded: 0

Tootekood: METSEPM5111

Quick Overview

Saadavus: Tellimisel

284,45 € (ilma KM-ta)

Details

Main
range
PowerLogic
product name
PowerLogic PM5000
device short name
PM5111
product or component type
Power meter
Complementary
power quality analysis
up to the 15th harmonic
device application
Power monitoring
type of measurement
Current
Voltage
Frequency
Power factor
Energy
Active and reactive power
supply voltage
100...415 V AC 45...65 Hz
125...250 V DC
network frequency
50 Hz
60 Hz
[In] rated current
5 A
1 A
type of network
3P
1P + N
3P + N
maximum power consumption in VA
10 VA 415 V
ride-through time
80 ms 120 V AC typical
100 ms 230 V AC typical
100 ms 415 V AC typical
display type
Backlit LCD
display resolution
128 x 128 pixels
sampling rate
64 samples/cycle
measurement current
10…9000 mA
analogue input type
voltage 5 MOhm)
current 0.3 MOhm)
measurement voltage
35…690 V AC 45...65 Hz between phases
20…400 V AC 45...65 Hz between phase and neutral
frequency measurement range
45…65 Hz
number of inputs
0
measurement accuracy
Active energy +/- 0.5 %
Reactive energy +/- 2 %
Active power +/- 0.5 %
Apparent power +/- 0.5 %
Frequency +/- 0.05 %
Power factor +/- 0.005 %
Current +/- 0.5 %
Voltage +/- 0.5 %
accuracy class
Class 0.5S active energy IEC 62053-22
number of outputs
1 digital
communication port protocol
Modbus RTU and ASCII 9.6, 19.2 and 38.4 kbauds even/odd or none - 2 wires 2500 V
JBUS
communication port support
RS485
data recording
Time stamping
Min/max of instantaneous values
connections - terminals
Voltage circuit screw terminal block4
Control circuit screw terminal block2
Current transformer screw terminal block6
Input/output circuit screw terminal block6
RS485 link screw terminal block4
mounting mode
Flush-mounted
mounting support
Framework
standards
IEC 61557-12
EN 50470-1
UL 61010-1
IEC 62053-24
IEC 60529
EN 50470-3
IEC 62053-22
product certifications
CE IEC 61010-1
CULus UL 61010-1
MID EN 50470-1
MID EN 50470-3
width
96 mm
depth
72 mm
height
96 mm
net weight
380 g
Environment
electromagnetic compatibility
Limits for harmonic current emissionsclass A IEC 61000-3-2
Electrostatic dischargelevel 4 IEC 61000-4-2
Conducted RF disturbanceslevel 3 IEC 61000-4-6
Magnetic field at power frequencylevel 4 IEC 61000-4-8
Conducted and radiated emissionsclass B EN 55022
IP degree of protection
Front IP52 IEC 60529
Body IP30 IEC 60529
relative humidity
5…95 % 50 °C
pollution degree
2
ambient air temperature for operation
-25…70 °C
ambient air temperature for storage
-40…85 °C
operating altitude
2000 m
Offer Sustainability
Jätkusuutliku pakkumise olek
Green Premium toode
Ilma SVHC REACh-ta
Jah
ELi RoHS direktiiv
Elavhõbedavaba
Jah
RoHS eranditeave
Hiina EoHS regulatsioon
Keskkonnaalane avaldus
Ringlusprofiil
WEEE
Tootest tuleb Euroopa Liidu turgudel vabaneda vastavuses erijäätmeseadustele ning see ei tohi sattuda olmeprügi sekka.
