extended I/O module - discrete 6I/2O

Details

Main
product or component type	Additional I/O module
range compatibility	Altivar Process ATV600 Altivar Machine ATV340 Altivar Process ATV900 Easy Altivar 610
input/output type	2 analog input configurable voltage, current or probe 6 discrete input 2 discrete output
analogue input number	2
analogue input type	AI1, AI2 configurable current: 0...20 mA/4...20 mA, sampling time: 0…1 ms, resolution: 14 bits AI1, AI2 configurable voltage: - 10...10 V DC, 24 V max, impedance: 20 kOhm, sampling time: 0…1 ms, resolution: 14 bits AI1, AI2 configurable PTC, Pt 100, Pt 1000, sampling time: 0…1 ms, resolution: 14 bits
discrete output number	2
discrete output type	(DQ11, DQ12) assignable logic, sampling time: 1 ms
discrete output logic	(DQ11, DQ12) negative (DQ11, DQ12) positive
discrete input number	6
discrete input type	(DI11...DI16) programmable, impedance: 250 Ohm, sampling time: 1 ms
discrete input logic	Negative (DI11...DI16) Positive (DI11...DI16)
discrete input current	2.5 mA

Complementary
discrete output voltage	24 V DC (voltage limits: <= 30 V) assignable logic
maximum output current	100 mA, assignable logic
discrete input voltage	24 V DC (voltage limits: <= 30 V) for programmable
electrical connection	Removable spring terminal block, 1.5 mm² / AWG 16
protection type	Reverse polarity protection: digital input Short-circuit protection: output
net weight	0.5 kg

Offer Sustainability
EU RoHS Directive	Pro-active compliance (Product out of EU RoHS legal scope) EU RoHS Declaration
Mercury free	Yes
RoHS exemption information	Yes
China RoHS Regulation	China RoHS declaration
