foot switch XPE-M - w/o cover - metal - blue - 2NC+1NO - protection against dust

Ülevaaded: 0

Tootekood: XPEM111EX

Quick Overview

Saadavus: Tellimisel

183,99 € (ilma KM-ta)

Details

Main
range of product
Harmony XPE
product or component type
Foot switch
material
Metal
foot switch type
Single foot switch
device short name
XPEM
protective cover
Without
trigger mechanism
Without trigger mechanism
contact operation
1 step
contacts type and composition
2 NC + 1 NO
colour
Blue
Complementary
positive opening
With EN/IEC 60947-5-1 appendix K
connections - terminals
Screw clamp terminal, <= 1 x 2.5 mm² with or without cable end
Screw clamp terminal, <= 2 x 1.5 mm² with or without cable end
cable entry
2 tapped entries Pg 16
marking
II2 D-Ex tD A21 IP65 T85°C
mechanical durability
5000000 cycles
[Ie] rated operational current
3 A 240 V, AC-15, A300
0,27 A 250 V, DC-13, Q300 EN/IEC 60947-5-1 appendix A
[Ui] rated insulation voltage
300 VUL 508
500 V 3)EN/IEC 60947-1
500 V 3)NF C 20-040 group C
500 V 3)VDE 0110 group C
300 VCSA C22.2 No 14
[Uimp] rated impulse withstand voltage
6 kV EN/IEC 60947-1
6 kV IEC 60664
maximum resistance across terminals
0,025 mOhm IEC 60255-7 category 3
0,025 mOhm NF C 93-050 method A
short-circuit protection
10 A cartridge fuse gG EN/IEC 60947-5-1
10 A cartridge fuse gG VDE 0660-200
width
104 mm
depth
172 mm
height
59 mm
Environment
standards
EN 50281-1-1
ATEX D 94/9/CE
EN 50014
IEC 61241-0
IEC 61241-1
dust zone
Zone 21 - 22
product certifications
INERIS 04ATEX0025
protective treatment
TC
ambient air temperature for operation
-20…60 °C
ambient air temperature for storage
-40…70 °C
vibration resistance
15 gn 10…500 Hz)IEC 60068-2-6
shock resistance
150 gn NF E 09-031
20 gn IEC 60068-2-27
electrical shock protection class
Class I EN/IEC 61140
Class I NF C 20-030
IP degree of protection
IP66
Offer Sustainability
Jätkusuutliku pakkumise olek
Green Premium toode
REACh-määrus
ELi RoHS direktiiv
Ennetav vastavus (toode ei jää EL-i RoHS seadustega määratud piiridesse)
ELi RoHS deklaratsioon
Mürgiste raskemetallideta
Jah
Elavhõbedavaba
Jah
RoHS eranditeave
Hiina EoHS regulatsioon
Keskkonnaalane avaldus
WEEE
Tootest tuleb Euroopa Liidu turgudel vabaneda vastavuses erijäätmeseadustele ning see ei tohi sattuda olmeprügi sekka.
Contractual warranty
Garantii
18 months
