green light block with body/fixing collar with integral LED 12...24V

Product was successfully added to your shopping cart.

green light block with body/fixing collar with integral LED 12...24V

Tootekood: ZB6EB3B

Quick Overview

Saadavus: Tellimisel

5,60 € (ilma KM-ta)

Qty:

Details

Main
range of product	Harmony XB6
product or component type	Complete body for pilot lights
device short name	ZB6
sale per indivisible quantity	5
connections - terminals	Faston connectors 2.8 x 0.5 mm
light source	LED
bulb base	Integral LED
light block supply	Direct
light source colour	Green
[Us] rated supply voltage	12...24 V AC/DC

Complementary
net weight	0,003 kg
operating position	Any position
[Ui] rated insulation voltage	250 V 3)EN/IEC 60947-1
[Uimp] rated impulse withstand voltage	4 kV EN 60947-1
signalling type	Steady
supply voltage limits	6…30 V AC/DC
current consumption	15 mA
surge withstand	1 kV in contact IEC 61000-4-5 2 kV in free air IEC 61000-4-5

Environment
protective treatment	TC
ambient air temperature for storage	-40…70 °C
ambient air temperature for operation	-25…70 °C
electrical shock protection class	Class II IEC 61140
standards	JIS C 852 EN/IEC 60947-5-1 JIS C 4520 EN/IEC 60947-1 CSA C22.2 No 14 UL 508 EN/IEC 60947-5-5
product certifications	GOST CSA CCC UL
vibration resistance	+/- 3 mm 2…500 Hz)IEC 60068-2-6 5 gn 2…500 Hz)IEC 60068-2-6
shock resistance	30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
resistance to fast transients	2 kV IEC 61000-4-4
resistance to electromagnetic fields	10 V/m IEC 61000-4-3
resistance to electrostatic discharge	6 kV on contact (on metal parts) IEC 61000-2-6 8 kV in free air (in insulating parts) IEC 61000-2-6
electromagnetic emission	Class B IEC 55011

Offer Sustainability
Jätkusuutliku pakkumise olek	Green Premium toode
REACh-määrus	REACh-deklaratsioon
ELi RoHS direktiiv	Ennetav vastavus (toode ei jää EL-i RoHS seadustega määratud piiridesse) ELi RoHS deklaratsioon
Elavhõbedavaba	Jah
RoHS eranditeave	Jah
Hiina EoHS regulatsioon	Hiina RoHS deklaratsioon
Keskkonnaalane avaldus	Toote keskkonnaprofiil
Ringlusprofiil	Kasutuselt kõrvaldamise teave
WEEE	Tootest tuleb Euroopa Liidu turgudel vabaneda vastavuses erijäätmeseadustele ning see ei tohi sattuda olmeprügi sekka.

Contractual warranty
Garantii	18 months
