Illuminated emergency stop head, plastic, red, Ø22, trigger latching turn to release, red LED, 24 V AC/DC

Ülevaaded: 0

Tootekood: ZB5AS84W2B

Quick Overview

Saadavus: Tellimisel

26,64 € (ilma KM-ta)

Details

Main
range of product
Harmony XB5
product or component type
Head for illuminated emergency stop push-button
device short name
ZB5
product compatibility
ZB5
bezel material
Plastic
mounting diameter
22 mm
sale per indivisible quantity
1
head type
Standard
shape of signaling unit head
Round
type of operator
trigger action and mechanical latching
reset
Turn to release
operator profile
Red square 32 mm
Complementary
CAD overall width
60 mm
CAD overall height
60 mm
CAD overall depth
40 mm
net weight
0.055 kg
resistance to high pressure washer
7000000 Pa at 55 °C, distance : 0.1 m
[Us] rated supply voltage
24 V AC/DC at 50...60 Hz
supply voltage limits
19.2…30 V DC
21.6…26.4 V AC
mechanical durability
300000 cycles
main group
E-stop
group of product
Emergency stop turn to release
cap/operator or lens colour
Red
marking
Unmarked
electrical composition code
C7 for <4 contacts using single blocks in front mounting
C8 for <4 contacts using single and double blocks in front mounting
C11 for <3 contacts using single blocks in front mounting
C15 for <1 contacts using single blocks in front mounting
SF1 for <3 contacts using single blocks in front mounting
SR1 for <3 contacts using single blocks in rear mounting
C10 for <4 contacts using single and double blocks in front mounting
light source colour
Red
device presentation
Basic element
Environment
protective treatment
TH
ambient air temperature for storage
-40…70 °C
ambient air temperature for operation
-40…70 °C
overvoltage category
Class II conforming to IEC 60536
IP degree of protection
IP66 conforming to IEC 60529
IP67 conforming to IEC 60529
IP69 conforming to IEC 60529
IP69K conforming to ISO 20653
Type 13 conforming to UL 50E
Type 12 conforming to UL 50E
Type 4 conforming to UL 50E
Type 4X conforming to UL 50E
NEMA degree of protection
NEMA 13
NEMA 4X
IK degree of protection
IK03 conforming to IEC 50102
standards
EN/IEC 60947-5-1
EN/IEC 60947-5-4
UL 508
product certifications
UL listed
CSA
EAC
vibration resistance
5 gn (f= 2…500 Hz) conforming to IEC 60068-2-6
shock resistance
30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27
50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27
Offer Sustainability
Sustainable offer status
Green Premium product
REACh Regulation
REACh free of SVHC
Yes
EU RoHS Directive
Pro-active compliance (Product out of EU RoHS legal scope)
EU RoHS Declaration
Toxic heavy metal free
Yes
Mercury free
Yes
RoHS exemption information
China RoHS Regulation
Environmental Disclosure
Circularity Profile
WEEE
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Contractual warranty
Warranty
18 months
