Details
Characteristics
| range of product | Harmony XVM | |
|---|---|---|
| product or component type | Pre-assembled and pre-cabled indicator bank | |
| beacon or indicator bank unit type | 2 illuminated units | |
| component name | XVM | |
| light source | Green super bright LED with BA 15d base steady signalling Red super bright LED with BA 15d base steady signalling | |
| light block color | Red/green | |
| [Us] rated supply voltage | 230 V AC | |
| indicator bank base type | Base with integrated buzzer | |
| mounting mode | Horizontal |
| kit composition | CoverPlastic fixing plateBase unitAluminium support tube | |
|---|---|---|
| mounting diameter | 45 mm | |
| connections - terminals | Flying leads,clamping capacity: 1 x 0.325 mm² (AWG 22) | |
| marking | CE | |
| mounting support | Aluminium tube | |
| short-circuit protection | 0.2 A | |
| [Ui] rated insulation voltage | 250 V conforming to IEC 60947-1 | |
| nominal voltage limit | 0.85...1.1 Un conforming to IEC 60947-5-1 | |
| current consumption | 18 mA on base unit15 mA on steady LED unit | |
| [Uimp] rated impulse withstand voltage | 4 kV IEC 60947-1 | |
| fundamental frequency | 4 kHz |
| IP degree of protection | IP54 horizontal position conforming to IEC 60529 | |
|---|---|---|
| product certifications | CCC | |
| standards | EN/IEC 60947-5-1EN/IEC 60947-1 | |
| ambient air temperature for storage | -25…70 °C | |
| ambient air temperature for operation | -10…50 °C | |
| overvoltage category | Class I conforming to IEC 60947-1Class I conforming to IEC 60947-5-1Class I conforming to IEC 61140 | |
| protective treatment | TC | |
| noise level | 0…80 dB at 1 m |
| Warranty | 18 months |
|---|
