Details
Characteristics
| range of product | OsiSense XS | |
|---|---|---|
| series name | General purpose | |
| sensor type | Inductive proximity sensor | |
| product specific application | - | |
| sensor name | XS5 | |
| sensor design | Form 8 x 43 x 8 | |
| size | 8 mm | |
| body type | Fixed | |
| enclosure material | Nickel plated brass | |
| type of output signal | Discrete | |
| wiring technique | 3-wire | |
| [Sn] nominal sensing distance | 1.5 mm | |
| discrete output function | 1 NO | |
| discrete output type | PNP | |
| electrical connection | Cable | |
| cable length | 2 m | |
| [Us] rated supply voltage | 12...24 V DC | |
| switching capacity in mA | <= 200 mA | |
| IP degree of protection | IP67 |
| detection face | Lateral top | |
|---|---|---|
| detector flush mounting acceptance | Flush mountable | |
| material | Metal | |
| front material | PPS | |
| output circuit type | DC | |
| cable composition | 3 x 0.11 mm² | |
| wire insulation material | PvR | |
| switching frequency | <= 2500 Hz | |
| marking | CE | |
| depth | 8 mm | |
| height | 8 mm | |
| width | 43 mm | |
| net weight | 0.1 kg |
| product certifications | UL | |
|---|---|---|
| ambient air temperature for operation | -25…70 °C |
| Sustainable offer status | Green Premium product | |
|---|---|---|
| REACh Regulation | ||
| EU RoHS Directive | Pro-active compliance (Product out of EU RoHS legal scope) EU RoHS Declaration | |
| Mercury free | Yes | |
| RoHS exemption information | ||
| Environmental Disclosure | ||
| Circularity Profile |
| Warranty | 18 months |
|---|
