inductive sensor XS8 40x40x70 - PBT - Sn40 mm - 24..240VAC/DC

Details

Main
range of product	OsiSense XS
series name	General purpose
sensor type	Inductive proximity sensor
device application	-
sensor name	XS8
sensor design	Form 40 x 40 x 70
size	70 mm
body type	Fixed
detector flush mounting acceptance	Non flush mountable
material	Plastic
enclosure material	PBT
type of output signal	Discrete
wiring technique	2-wire
[Sn] nominal sensing distance	40 mm
discrete output function	1 NO
output circuit type	AC/DC
electrical connection	Male connector 1/2"20 UNF, 3 pins
[Us] rated supply voltage	24...240 V AC 50/60 Hz 24...240 V DC
switching capacity in mA	5...200 mA DC 5...300 mA AC
IP degree of protection	IP67 conforming to IEC 60529 IP65 conforming to IEC 60529 IP69K conforming to DIN 40050

Complementary
detection face	5 positions turret head
front material	PBT
operating zone	0…32 mm
differential travel	3...15% of Sr
repeat accuracy	<= 3% of Sr
status LED	Supply on: 1 LED (green) Output state: 1 LED (yellow)
supply voltage limits	20…264 V AC/DC
maximum residual current	1.5 mA open state 120 V 0.6 mA open state 24 V
switching frequency	<= 25 Hz AC <= 50 Hz DC
maximum voltage drop	<5.5 V (closed)
maximum delay first up	7.5 ms
maximum delay response	1.4 ms
maximum delay recovery	2.5 ms
marking	CE
height	40 mm
length	40 mm
width	70 mm
net weight	0.149 kg

Environment
product certifications	UL CSA CCC
ambient air temperature for operation	-25…70 °C
ambient air temperature for storage	-40…85 °C
vibration resistance	25 gn amplitude = +/- 2 mm (f = 10…55 Hz) conforming to IEC 60068-2-6
shock resistance	50 gn for 11 ms conforming to EN 60068-2-27

Offer Sustainability
Sustainable offer status	Green Premium product
REACh Regulation	REACh Declaration
EU RoHS Directive	Pro-active compliance (Product out of EU RoHS legal scope) EU RoHS Declaration
Mercury free	Yes
RoHS exemption information	Yes
Environmental Disclosure	Product Environmental Profile

Contractual warranty
Warranty	18 months
