input interface module - 17.5 mm - electromechanical - 24 V AC/DC - 2 NO

Ülevaaded: 0

Tootekood: ABR1E418B

Quick Overview

Saadavus: Ei saa enam tellida

61,00 € (ilma KM-ta)

Details

Main
range of product
Interface for discrete signals
product or component type
Electromechanical input interface module
contacts type and composition
2 NO
[Uc] control circuit voltage
24 V
control circuit type
AC/DC
control circuit frequency
50/60 Hz
width pitch dimension
17,5 mm
maximum [In] rated current
55 mA AC
62 mA DC
reverse polarity protection
with
short-circuit protection
16 A external fuse gF Ik <= 2.5 kA AC and Ik <= 100 A DC)
16 A external fuse gG Ik <= 2.5 kA AC and Ik <= 100 A DC)
[Ith] conventional free air thermal current
2 A IEC 60947-1
local signalling
Green mechanical indicator for position of contacts 1 green LED control signal state
Complementary
control circuit voltage limits
30 V 16.5 V
housing colour
Grey
connections - terminals
Screw clamp terminal
drop-out voltage
3,8 V
minimum holding current
4,9 mA DC
5,2 mA AC
maximum power dissipation in W
1,5 W
maximum switching voltage
125 V DC
252 V AC
[Ue] rated operational voltage
<= 125 V DC IEC 60947-5-1
<= 230 V AC IEC 60947-5-1
network frequency
50/60 Hz
[Ie] rated operational current
1 A AC-13 Ue: 230 V 1000000 cycles IEC 60947-5-1
1 A AC-14 Ue: 230 V 1000000 cycles IEC 60947-5-1
1 A AC-15 Ue: 230 V 1000000 cycles IEC 60947-5-1
1 A DC-13 Ue: 24 V 1000000 cycles IEC 60947-5-1
2 A AC-12 Ue: 230 V 1000000 cycles IEC 60947-5-1
2 A DC-12 Ue: 24 V 1000000 cycles IEC 60947-5-1
minimum switching current
3 mA
minimum switching voltage
17 V
electrical reliability
<= 0.00000001
operating time
<= 12 ms between de-energisation of coil and closing of NC contact
<= 12 ms between de-energisation of coil and closing of NO contact
<= 12 ms between energisation of coil and closing of NC contact
<= 12 ms between energisation of coil and closing of NO contact
contact bounce time
<= 3 ms
operating rate in Hz
6 Hz at no-load
0,5 Hz at Ie
mechanical durability
20000000 cycles
[Ui] rated insulation voltage
250 V IEC 60947-1
250 V VDE 0110 group C
flame retardance
V0 UL 94
cable cross section
0,34…2,5 mm², 1 or 2 wires flexible with cable end
0,6…2,5 mm², 1 or 2 wires flexible without cable end
0,27…2,5 mm², 2 wires rigid
0,27…4 mm², 1 wire rigid
operating position
Any position
installation category
II IEC 60947-1
mounting support
Combination rail
Asymmetrical DIN rail
Symmetrical DIN rail
net weight
0,095 kg
Environment
immunity to microbreaks
8 ms
dielectric strength
1500 V between independent contacts
2500 V between wired interface and earth
4000 V between coil circuit and contact circuits
standards
IEC 60947-5-1
product certifications
BV
UL
LROS (Lloyds register of shipping)
DNV
CSA
IP degree of protection
IP20 IEC 60529
protective treatment
TC
fire resistance
850 °C IEC 60695-2-1
shock resistance
50 gn 11 ms IEC 60068-2-27
vibration resistance
6 gn 10…55 Hz)IEC 60068-2-6
electromagnetic compatibility
1.2/50 ms shock waves immunity test IEC 255-4
1.2/50 ms shock waves immunity test IEC 255-4
Electrostatic discharge immunity test, level 3 8 kV IEC 61000-4-2
Rapid transients immunity test on input/output 1 kV IEC 61000-4-4
Rapid transients immunity test on power supply 2 kV IEC 61000-4-4
ambient air temperature for operation
-20…60 °C at Un
-5…40 °C unrestricted operation
ambient air temperature for storage
-40…70 °C
operating altitude
<= 3000 m
pollution degree
3 IEC 60947-5-1
Offer Sustainability
Jätkusuutliku pakkumise olek
Green Premium toode
ELi RoHS direktiiv
Ennetav vastavus (toode ei jää EL-i RoHS seadustega määratud piiridesse)
ELi RoHS deklaratsioon
Mürgiste raskemetallideta
Jah
Elavhõbedavaba
Jah
RoHS eranditeave
Hiina EoHS regulatsioon
Keskkonnaalane avaldus
WEEE
Tootest tuleb Euroopa Liidu turgudel vabaneda vastavuses erijäätmeseadustele ning see ei tohi sattuda olmeprügi sekka.
Contractual warranty
Garantii
18 months
