light block with body/fixing collar for incandescent bulb <=24V

Tootekood: ZB6EH0B

Quick Overview

Saadavus: Tellimisel

14,40 € (ilma KM-ta)

Qty:

Details

Main
range of product	Harmony XB6
product or component type	Complete body for pilot lights
device short name	ZB6
sale per indivisible quantity	5
connections - terminals	Faston connectors, connection size: 2.8 x 0.5 mm
light source	Incandescent (bulb not included)
bulb base	BA 9s
light block supply	Direct
[Us] rated supply voltage	<= 24 V AC/DC

Complementary
terminals description ISO n°1	(X1-X2)PL
net weight	0.003 kg
operating position	Any position
[Ui] rated insulation voltage	250 V (pollution degree 2) conforming to EN/IEC 60947-1
[Uimp] rated impulse withstand voltage	EN 60947-1 4 kV
signalling type	Steady

Environment
protective treatment	TC
ambient air temperature for storage	-40…70 °C
ambient air temperature for operation	-25…70 °C
electrical shock protection class	Class II conforming to IEC 61140
standards	UL 508 EN/IEC 60947-5-5 EN/IEC 60947-1 JIS C 4520 CSA C22.2 No 14 JIS C 852 EN/IEC 60947-5-1
product certifications	GOST UL CCC CSA
vibration resistance	+/- 3 mm (f= 2…500 Hz) conforming to IEC 60068-2-6 5 gn (f= 2…500 Hz) conforming to IEC 60068-2-6
shock resistance	30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27 50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27

Offer Sustainability
Sustainable offer status	Green Premium product
REACh Regulation	REACh Declaration
EU RoHS Directive	Pro-active compliance (Product out of EU RoHS legal scope) EU RoHS Declaration
Mercury free	Yes
RoHS exemption information	Yes
China RoHS Regulation	China RoHS declaration
Environmental Disclosure	Product Environmental Profile
Circularity Profile	End of Life Information
WEEE	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins

Contractual warranty
Warranty	18 months
