light curtain transmitter XU2-S - detection of body - 12..24 V - 3 x 0.34 mm²

Ülevaaded: 0

Tootekood: XU2S18KP340WL5T

Quick Overview

Saadavus: Ei saa enam tellida

183,76 € (ilma KM-ta)

Details

Main
range of product
Preventa Safety detection
product or component type
Safety thru-beam transmitter photo-electric sensors
device short name
XU2S
product compatibility
XPSCM1144P
XPSCM1144
[Sn] nominal sensing distance
8 m
Complementary
detection system
Transmitter-receiver system
[Us] rated supply voltage
12...24 V DC (10...30 V)against reverse polarity
current consumption
<= 35 mA no-load
line of sight type
90° to case axis
electrical connection
Pre-cabled
cable outer diameter
5 mm
cable length
5 m
cable composition
3 x 0.34 mm²
tightening torque
24 N.m fixing nut
marking
CE
material
Nickel plated brass: case
PMMA (polymethyl methacrylate): lenses
net weight
0.235 kg
Environment
ambient air temperature for operation
-25…55 °C
ambient air temperature for storage
-40…70 °C
IP degree of protection
IP67 conforming to EN/IEC 60529
shock resistance
30 gn 3 axes : 3 times conforming to EN/IEC 60068-2-27
vibration resistance
7 gn (f= 10…55 Hz) conforming to EN/IEC 60068-2-6
Offer Sustainability
Sustainable offer status
Green Premium product
REACh Regulation
EU RoHS Directive
Pro-active compliance (Product out of EU RoHS legal scope)
EU RoHS Declaration
Mercury free
Yes
RoHS exemption information
Environmental Disclosure
Circularity Profile
Contractual warranty
Warranty
18 months
