limit switch body ZCMD - 1NC+1NO - gold - snap action - connection - M12

Tootekood: ZCMD61M12

Quick Overview

Saadavus: Ei saa enam tellida

40,50 € (ilma KM-ta)

Details

Main
range of product	OsiSense XC
series name	Standard format
product or component type	Limit switch body
device short name	ZCMD
design	Miniature
body type	Fixed
associated head	ZCE01 ZCE63 ZCEF2 ZCE21 ZCEG1 ZCE66 ZCE28 ZCE27 ZCE08 ZCE07 ZCE24 ZCE13 ZCE02 ZCEF0 ZCE29 ZCE14 ZCE65 ZCE64 ZCE11 ZCE09 ZCE62 ZCE10 ZCE67 ZCE06
body material	Zamak
number of poles	1
contacts type and composition	1 C/O
contact operation	Snap action

Complementary
product compatibility	XCMD
electrical connection	Male connector M12, 4 pins
contacts insulation form	Za
contacts material	Gold plated contacts
positive opening	Without
minimum actuation speed	0.01 m/min
[Ie] rated operational current	0.1 A at 250 V, DC-13 conforming to EN/IEC 60947-5-1 appendix A 1.5 A at 240 V, AC-15 conforming to EN/IEC 60947-5-1 appendix A
[Ithe] conventional enclosed thermal current	3 A
[Ui] rated insulation voltage	300 V (pollution degree 3) conforming to UL 508 300 V (pollution degree 3) conforming to CSA C22.2 No 14 250 V (pollution degree 3) conforming to IEC 60947-5-1
maximum resistance across terminals	25 mOhm conforming to IEC 60255-7 category 3
[Uimp] rated impulse withstand voltage	IEC 60664 2.5 kV IEC 60947-1 2.5 kV
short-circuit protection	4 A cartridge fuse, type gG
electrical durability	5000000 cycles, DC-13 24 V, 3 W, operating rate <60 cyc/mn, load factor: 0.5 conforming to IEC 60947-5-1 appendix C 5000000 cycles, DC-13 48 V, 2 W, operating rate <60 cyc/mn, load factor: 0.5 conforming to IEC 60947-5-1 appendix C 5000000 cycles, DC-13 120 V, 1 W, operating rate <60 cyc/mn, load factor: 0.5 conforming to IEC 60947-5-1 appendix C
width	30 mm
height	50 mm
depth	16 mm
net weight	0.065 kg

Environment
ambient air temperature for storage	-40…70 °C

Offer Sustainability
Sustainable offer status	Green Premium product
REACh Regulation	REACh Declaration
EU RoHS Directive	Pro-active compliance (Product out of EU RoHS legal scope) EU RoHS Declaration
Mercury free	Yes
RoHS exemption information	Yes
Environmental Disclosure	Product Environmental Profile
Circularity Profile	End of Life Information

Contractual warranty
Warranty	18 months
