limit switch contact block - 1NC+1NO - slow-break, make before break

Ülevaaded: 0

Tootekood: XE2NP2161

Quick Overview

Saadavus: Tellimisel

11,57 € (ilma KM-ta)

Details

Main
range of product
OsiSense XC
series name
Standard format
product or component type
Limit switch contact block
device short name
XE2N
associated body
ZCP26
ZCD26
ZCKJ6D
ZCKM6
ZCKL6
ZCKJ6
ZCKS6
number of poles
2
contacts type and composition
1 NO + 1 NC
contact operation
Slow-break, make before break
Complementary
product compatibility
XCKM
XCKS
XCKD
XCKL
XCKJ
XCKP
electrical connection
Screw-clamp terminals 1 x 0.5...2 x 2.5 mm²
contacts insulation form
Zb
contacts material
Silver plated contacts
positive opening
With
minimum actuation speed
6 m/min
contact code designation
A300, AC-15 (Ue = 240 V), Ie = 3 A 10 A EN/IEC 60947-5-1 appendix A
Q300, DC-13 (Ue = 250 V), Ie = 0,27 A EN/IEC 60947-5-1 appendix A
maximum resistance across terminals
25 mOhm IEC 60255-7 category 3
[Ui] rated insulation voltage
300 VUL 508
500 V 3)IEC 60947-1
300 VCSA C22.2 No 14
[Uimp] rated impulse withstand voltage
6 kV IEC 60664
6 kV IEC 60947-1
short-circuit protection
10 A cartridge fuse gG
electrical durability
5000000 cycles, DC-13 120 V, 7 W 60 cyc/mn 0,5 IEC 60947-5-1 appendix C
5000000 cycles, DC-13 24 V, 13 W 60 cyc/mn 0,5 IEC 60947-5-1 appendix C
5000000 cycles, DC-13 48 V, 9 W 60 cyc/mn 0,5 IEC 60947-5-1 appendix C
Offer Sustainability
Jätkusuutliku pakkumise olek
Green Premium toode
REACh-määrus
ELi RoHS direktiiv
Ennetav vastavus (toode ei jää EL-i RoHS seadustega määratud piiridesse)
ELi RoHS deklaratsioon
Elavhõbedavaba
Jah
RoHS eranditeave
Keskkonnaalane avaldus
Contractual warranty
Garantii
18 months
