metal key operated switch XCSA - 2NC + NO slow break - ATEX/IECEx

Ülevaaded: 0

Tootekood: XCSB702EX

Quick Overview

Saadavus: Tellimisel

362,04 € (ilma KM-ta)

Details

Main
range of product
Preventa ATEX D
product or component type
Safety switch
device short name
XCSB
material
Metal
head type
Key operated turret head
cable entry number
1 tapped entry for M20 x 1.5 cable gland (included) 7…13 mm
electrical connection
Terminal
clamping connection capacity
1 x 0.5...2 x 1.5 mm² with or without cable end
number of poles
3
contacts type and composition
2 NC + 1 NO
contact operation
Slow-break, break before make
positive opening
With NC contact
locking options description
With locking of actuator, unlocking by push-button
Complementary
local signalling
Without
mechanical durability
600000 cycles
minimum actuation speed
0.01 m/s
maximum actuation speed
0.5 m/s
contact code designation
A300, AC-15 (Ue = 120 V, Ie = 6 A) conforming to EN/IEC 60947-5-1
A300, AC-15 (Ue = 240 V, Ie = 3 A) conforming to EN/IEC 60947-5-1
Q300, DC-13 (Ue = 125 V, Ie = 0.55 A) conforming to EN/IEC 60947-5-1
Q300, DC-13 (Ue = 250 V, Ie = 0.27 A) conforming to EN/IEC 60947-5-1
[Ithe] conventional enclosed thermal current
10 A
[Ui] rated insulation voltage
300 V conforming to UL 508
500 V conforming to EN/IEC 60947-1
300 V conforming to CSA C22.2 No 14
[Uimp] rated impulse withstand voltage
EN/IEC 60947-5-1 6 kV
short-circuit protection
10 A cartridge fuse type gG (gl)
actuator forcible withdrawal rtc
1500 N
minimum actuator force for extraction
20 N
maximum operating rate
10 cyc/mn for maximum durability
body material
Zamak
head material
Zamak
CAD overall width
52 mm
CAD overall height
114 mm
CAD overall depth
44 mm
net weight
0.475 kg
Environment
safety level
Can reach category 4 with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1
Can reach PL = e with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1
Can reach SIL 3 with the appropriate monitoring system and correctly wired conforming to IEC 61508
safety reliability data
B10d = 5000000 value given for a life time of 20 years limited by mechanical or contact wear
protective treatment
TC
ambient air temperature for operation
-25…70 °C
ambient air temperature for storage
-40…70 °C
vibration resistance
5 gn (f= 10…500 Hz) conforming to IEC 60068-2-6
shock resistance
10 gn for 11 ms conforming to IEC 60068-2-27
electrical shock protection class
Class I conforming to EN/IEC 60536
IP degree of protection
IP67 conforming to EN/IEC 60529 and EN/IEC 60947-5-1
marking
II2 D-Ex tb IIIC T85°C Db IP67
dust zone
Zone 21 - 22
product certifications
IEC-Ex INE 17.0020X
INERIS 04ATEX0014X
standards
EN/IEC 60079-31
EN/IEC 60079-0
directives
2014/34/EU - ATEX directive
Offer Sustainability
Sustainable offer status
Green Premium product
REACh Regulation
EU RoHS Directive
Pro-active compliance (Product out of EU RoHS legal scope)
EU RoHS Declaration
Mercury free
Yes
RoHS exemption information
Environmental Disclosure
Contractual warranty
Warranty
18 months
