Modicon Quantum DIO head-end adaptor - fibre optic cable medium

Ülevaaded: 0

Tootekood: 140NOM25200C

Quick Overview

Saadavus: Ei saa enam tellida

1 874,11 € (ilma KM-ta)

Details

Main
range of product
Modicon Quantum automation platform
product or component type
DIO head-end adaptor
Complementary
number of port
1 Modbus Plus fiber optic single copper
1 Modbus RS232 twisted pair
transmission rate
1 Mbit/s
electrical connection
1 connector RJ45
2 connectors TX/RX
I/O words
30 I/32 O
checks
RAM
Checksum
Processor
RAM address
power dissipation in W
4 W
minimum pulse width distortion/jitter
5 ns
wavelength
820 nm
power loss budget
11 dB 62.5/125 µm
16.5 dB 100/140 µm
6.5 dB 50/125 µm
optical transmission
-16…-9 dBm 100/140 µm
-19.8…-12.8 dBm 50/125 µm
-3.5…110.5 dBm 62.5/125 µm
rise/fall time
20 ns
dynamic range
20 dB
detected silence
-36 dBm
sensitivity scale
> 30 dBm
bus current requirement
750 mA
Environment
resistance to electrostatic discharge
4 kV contact conforming to IEC 801-2
8 kV on air conforming to IEC 801-2
resistance to electromagnetic fields
10 V/m 80…2000 MHz conforming to IEC 801-3
ambient air temperature for operation
0…60 °C
ambient air temperature for storage
-40…85 °C
relative humidity
95 % without condensation
operating altitude
<= 5000 m
protective treatment
Conformal coating Humiseal 1A33
standards
UL 508
product certifications
RINA
RMRS
DNV
GOST
GL
CSA Class 1 Division 2
C-Tick
Offer Sustainability
Sustainable offer status
Green Premium product
REACh Regulation
EU RoHS Directive
Pro-active compliance (Product out of EU RoHS legal scope)
EU RoHS Declaration
Mercury free
Yes
RoHS exemption information
China RoHS Regulation
Environmental Disclosure
Circularity Profile
WEEE
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Contractual warranty
Warranty
18 months
