Modicon Quantum discrete input module - 34 I - 10..60 V - positive logic

Product was successfully added to your shopping cart.

Modicon Quantum discrete input module - 34 I - 10..60 V - positive logic

Tootekood: 140DDI85300C

Quick Overview

Saadavus: Ei saa enam tellida

732,60 € (ilma KM-ta)

Details

Main
range of product	Modicon Quantum automation platform
product or component type	Dc discrete input modules
discrete input number	32

Complementary
group of channels	4
logic input	Positive (sink)
input voltage limits	10...60 V
input voltage	12 V 5…10 mA DC 24 V 6…30 mA DC 48 V 2…15 mA DC 60 V 1…5 mA DC
voltage state 1 guaranteed	9...12 V 12 V +/- 5 % 11...24 V 24 V - 15...20 % 34...48 V 48 V - 15...20 % 45...60 V 60 V - 15...20 %
voltage state 0 guaranteed	0...1.8 V 12 V +/- 5 % 0...10 V 48 V - 15...20 % 0...12.5 V 60 V - 15...20 % 0...5 V 24 V - 15...20 %
absolute maximum voltage	75 V
addressing requirement	2 input words
response time	4 ms from state 0 to state 1 4 ms from state 1 to state 0
switching frequency	<= 100 Hz
isolation between group and bus	2500 Vrms DC for 1 minute
isolation between group	700 Vrms DC for 1 minute
power dissipation	1 W + (0.25 x number of points on)
marking	CE
local signalling	1 LED (green)bus communication is present (Active): 32 LEDs (green)input status:
bus current requirement	300 mA
module format	Standard
net weight	0.295 kg

Environment
protective treatment	Conformal coating Humiseal 1A33
standards	CSA C22.2 No 142 UL 508 EN/IEC 61131-2
product certifications	CSA CE ATEX Merchant Navy IEC-Ex UL EAC RCM Hazardous location class 1, division 2
resistance to electrostatic discharge	4 kV contact conforming to IEC 801-2 8 kV on air conforming to IEC 801-2
resistance to electromagnetic fields	10 V/m 80…2000 MHz conforming to IEC 801-3
ambient air temperature for operation	0…60 °C
ambient air temperature for storage	-40…85 °C
relative humidity	95 % without condensation
operating altitude	<= 5000 m

Offer Sustainability
Sustainable offer status	Green Premium product
REACh Regulation	REACh Declaration
EU RoHS Directive	Pro-active compliance (Product out of EU RoHS legal scope) EU RoHS Declaration
Mercury free	Yes
RoHS exemption information	Yes
China RoHS Regulation	China RoHS declaration
Environmental Disclosure	Product Environmental Profile
Circularity Profile	End of Life Information
WEEE	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins

Contractual warranty
Warranty	18 months
