Multi 9 - comb busbar - 3L - 18 mm pitch - 12 modules - 100A

Tootekood: 10287

Quick Overview

Saadavus: Tellimisel

38,62 € (ilma KM-ta)

Details

Main
range
Multi 9
product or component type
Comb busbar
accessory / separate part category
Connection accessory
lines description
3L
Length in 18 mm modules
12
Complementary
number of ways
4 ways 3 L
poles configuration for 1 way
1 x 3P
connection pitch
18 mm
connector type
tooth
distance between way
54 mm
marking
L1 L2 L3
insulation
Insulated
device presentation
Uncuttable
[Ie] rated operational current
100 A 40 °C
[Ue] rated operational voltage
277 V AC Ph/N
480 V AC Ph/Ph
[Ui] rated insulation voltage
690 V AC
[Uimp] rated impulse withstand voltage
12 kV
mounting mode
Horizontal
mounting location
Top tunnel type terminals
9 mm pitches
24
width
216 mm
colour
Light grey RAL 7035)
range compatibility
Multi 9 C60SP
Environment
standards
IEC 60947-2
GB 14048.2
UL 1077
fire resistance
960 °C 30 s )
Offer Sustainability
REACh-määrus
Ilma SVHC REACh-ta
Jah
ELi RoHS direktiiv
Mürgiste raskemetallideta
Jah
Elavhõbedavaba
Jah
RoHS eranditeave
Hiina EoHS regulatsioon
Hiina RoHS deklaratsioon
Ennetav Hiina RoHS deklaratsioon (ei kuulu Hiina RoHS-i õigussfääri)
WEEE
Tootest tuleb Euroopa Liidu turgudel vabaneda vastavuses erijäätmeseadustele ning see ei tohi sattuda olmeprügi sekka.
Contractual warranty
Garantii
18 months
