Ø 70 mm audible unit - adjustable buzzer - 70...90 dB - 120..230 V

Ülevaaded: 0

Tootekood: XVDC9M

Quick Overview

Saadavus: Ei saa enam tellida

144,01 € (ilma KM-ta)

Details

Main
range of product
Harmony XVD Application
product or component type
Indicator bank
beacon or indicator bank unit type
Audible unit
mounting diameter
70 mm
component name
XVD
noise level
70…90 dB at 1 m
[Us] rated supply voltage
120...230 V AC
Complementary
signalling type
Continuous or intermittent buzzer
assembly style
Customer assembly, up to 5 units
connections - terminals
Screw clamp terminals, <= 1 x 1.5 mm² with cable end
[Ui] rated insulation voltage
250 V conforming to IEC 60947-1
nominal voltage limit
0.85...1.1 Un conforming to IEC 60947-5-1
current consumption
< 50 mA
[Uimp] rated impulse withstand voltage
IEC 60947-1 4 kV
fundamental frequency
2.8 kHz
net weight
0.15 kg
Environment
product certifications
CSA
UL
GOST
standards
EN/IEC 60947-5-1
protective treatment
TC
ambient air temperature for storage
-40…70 °C
ambient air temperature for operation
-25…50 °C
electrical shock protection class
Class I on support tube, with metal fixing plate conforming to IEC 60536
Class II on base unit conforming to IEC 60536
Class II on support tube, with plastic fixing plate conforming to IEC 60536
IP degree of protection
IP40 conforming to IEC 60529
Contractual warranty
Warranty
18 months
