output interface module - 9.5 mm - solid state - 24..230 V AC - 2.3 A

Ülevaaded: 0

Tootekood: ABS2SA01MB

Quick Overview

Saadavus: Ei saa enam tellida

80,79 € (ilma KM-ta)

Details

Main
range of product
Interface for discrete signals
product or component type
Slim solid state output interface module
contacts type and composition
1 NC
[Uc] control circuit voltage
24 V
control circuit type
DC
maximum [In] rated current
13,6 mA
reverse polarity protection
Control circuit internal
Output circuit internal
short-circuit protection
3,15 A external fuse fast blow Ik <= 1 kA AC and Ik <= 100 A DC)
[Ith] conventional free air thermal current
2,3 A 40 °C
local signalling
Green mechanical indicator for position of contacts 1 green LED control signal state
sale per indivisible quantity
5
width pitch dimension
9,5 mm
Complementary
control circuit voltage limits
28.8 V
voltage state 1 guaranteed
16.9 V
current state 1 guaranteed
8.3 mA
voltage state 0 guaranteed
5.3 V
current state 0 guaranteed
2 mA
[Ue] rated operational voltage
24...240 V
output circuit type
AC
rated operational voltage limits
<= 264 V
[Ie] rated operational current
1 A AC-15 vertical position, single product IEC 60947-5-1
1,6 A AC-13 vertical position, single product IEC 60947-5-1
1,6 A AC-14 vertical position, single product IEC 60947-5-1
1,9 A AC-12 vertical position, single product IEC 60947-5-1
0,5 A AC-12 vertical position, touching product IEC 60947-5-1
0,5 A AC-13 vertical position, touching product IEC 60947-5-1
0,5 A AC-14 vertical position, touching product IEC 60947-5-1
0,5 A AC-15 vertical position, touching product IEC 60947-5-1
minimum switching current
10 mA
maximum residual current
2,5 mA
drop-out voltage
3 V
1,5 V
dV/dt
500 V/µs
0 crossing voltage
50 V peak
response time
<= 10 ms from state 0 to state 1 50 Hz
<= 10 ms from state 1 to state 0 50 Hz
<= 8 ms from state 0 to state 1 60 Hz
<= 8 ms from state 1 to state 0 60 Hz
switching frequency
<= 0.6 Hz AC-13 module alone 40 %
<= 0.6 Hz AC-14 module alone 40 %
<= 0.6 Hz AC-15 module alone 40 %
<= 50 Hz on resistive load 50 %
[Ui] rated insulation voltage
250 V VDE 0110 group C
300 V IEC 60947-1
flame retardance
V0 UL 94
cable cross section
0,34…2,5 mm², 1 or 2 wires flexible with cable end screw clamp terminal
0,27…4 mm², 1 wire rigid
0,6…2,5 mm², 1 or 2 wires flexible without cable end
operating position
Any position
installation category
II IEC 60947-1
mounting support
Symmetrical DIN rail
Asymmetrical DIN rail
Combination rail
net weight
0,34 kg
Environment
dielectric strength
2500 V between wired interface and earth for 1 minute
4000 V between I/O for 1 minute
standards
IEC 60947-5-1
product certifications
UL
LROS (Lloyds register of shipping)
DNV
CSA
BV
IP degree of protection
IP20 IEC 60529
protective treatment
TC
fire resistance
960 °C IEC 60695-2-1
shock resistance
30 gn 11 ms IEC 60068-2-27
vibration resistance
5 gn 10…150 Hz)IEC 60068-2-6
electromagnetic compatibility
Electromagnetic field immunity test level 3 10 V/m between 27...1000 MHz IEC 61000-4-3
Electrostatic discharge immunity test level 3 8 kV IEC 61000-4-2
Fast transients immunity test level 3 on input/output 1 kV IEC 61000-4-4
Fast transients immunity test level 3 on power supply 2 kV IEC 61000-4-4
1.2/50 µs shock waves immunity test IEC 60947-1
1.2/50 µs shock waves immunity test IEC 60947-1
1.2/50 µs shock waves immunity test IEC 60947-1
ambient air temperature for operation
-25…70 °C at Us
-5…55 °C unrestricted operation
ambient air temperature for storage
-40…80 °C
operating altitude
<= 3000 m
pollution degree
2 IEC 60947-1
Offer Sustainability
ELi RoHS direktiiv
Ennetav vastavus (toode ei jää EL-i RoHS seadustega määratud piiridesse)
ELi RoHS deklaratsioon
Elavhõbedavaba
Jah
RoHS eranditeave
Hiina EoHS regulatsioon
WEEE
Tootest tuleb Euroopa Liidu turgudel vabaneda vastavuses erijäätmeseadustele ning see ei tohi sattuda olmeprügi sekka.
Contractual warranty
Garantii
18 months
