Details
Characteristics
| range of product | OsiSense XU | |
|---|---|---|
| series name | General purpose single mode | |
| electronic sensor type | Photo-electric sensor transmitter | |
| sensor name | XUL | |
| sensor design | Compact | |
| detection system | Thru beam | |
| material | Plastic | |
| supply circuit type | DC | |
| wiring technique | 2-wire | |
| electrical connection | 1 male connector M12, 4 pins | |
| emission | Infrared thru beam | |
| [Sn] nominal sensing distance | 8 m thru beam need a receiver |
| enclosure material | ABS | |
|---|---|---|
| lens material | PMMA | |
| [Us] rated supply voltage | 12...24 V DC with reverse polarity protection | |
| supply voltage limits | 10…30 V DC | |
| current consumption | <= 35 mA | |
| maximum delay first up | 15 ms | |
| setting-up | Without sensitivity adjustment | |
| depth | 35 mm | |
| height | 70 mm | |
| width | 18 mm | |
| net weight | 0.135 kg |
| product certifications | CE | |
|---|---|---|
| ambient air temperature for operation | -25…55 °C | |
| ambient air temperature for storage | -40…70 °C | |
| vibration resistance | 7 gn, amplitude = +/- 2 mm (f = 10…55 Hz) conforming to IEC 60068-2-6 | |
| shock resistance | 20 gn (duration = 11 ms) conforming to IEC 60068-2-27 | |
| IP degree of protection | IP67 conforming to IEC 60529IP671 conforming to NF C 20-010 |
| REACh Regulation | ||
|---|---|---|
| EU RoHS Directive | Not applicable, out of EU RoHS legal scope |
| Warranty | 18 months |
|---|
